mod.AWD129NA page 6
1180240 Spare parts list
Ref. Code From To S/N Substitute Description Notice Industrial
001 C00064786 1 x C00143260 bolt m8x23 torx tefl
002 C00013563 bearing fits light/heavy spider 25
003 C00064785 1 x C00193879 bolt m8x22 tb6lt
004 C00002591 bearing 20x47x14
005 C00096186 standard oil seal n1040300
n1040326
006 C00145190 rear support
007 C00088408 bolt + washer
008 C00087811 upper counterweight 8.2 kg
009 C00064517 tank cradle channel-top left right
011 C00080652 bolt m8x36 tefl. zig. p/p
012 C00141682 anchorage pad - suspension
013 C00080660 suspension spring - tank
014 C00080653 spacer
015 C00110429 door bellows seal wd 28-28 cm
016 C00064546 clamping ring - door seal front
017 C00064547 bellows clamp (tank front)
018 C00092178 front counterweight
019 C00092411 1 x C00094908 hose clamp
020 C00092174 hose tank to filter with oko ball
021 C00092412 hose clamp
022 C00091148 1 x C00094908 clamp d=79 mm
023 C00065152 nut romob m6x22x1,5
024 C00047136 1 x C00144571 nut romob m8
025 C00093848 cradle outer- set
026 C00110162 shock absorber 120 n 10,2 mm
027 C00064789 1 x C00268109 lifter - extractable
028 C00094281 1 x C00094275 outer- set 46 l. evo ii n1040300
1 x C00094280
031 C00092273 hose dispenser to tank
032 C00096077 bearing spider assembly n1040300
033 C00074211 drum pulley d=210 mm h=20 mm
034 C00118629 belt l=1046 - 1051 mm h8
037 C00110163 shock absorber elastic pin
099 C00001109 loctite 270 10 gr.
