mod.AWD129NA page 9
1180320A Spare parts
list
Ref. Code From To S/N Substitute Description Notice Industrial
001 C00098928 supply cable 1,50 mt usa
003 C00019902 plastic -u- to make drain hose
004 C00091775 drain hose to sink
005 C00088394 push button switch na idc
005 C00090218 deviator switch (on-off)
007 C00086663 pilot light red 12 v rast 2.5
008 C00090195 programme select elbi 1665 rast
009 C00143096 potentiometer select 8 posit. rosh
010 C00064537 1 x C00263210 support - pressure switch
011 C00046152 additive container
013 C00046148 1 x C00281253 soap dispenser drawer (rotary)
014 C00092176 dispenser body
015 C00090200 pressure switch 1l 90-65
016 C00092412 hose clamp
017 C00092170 1 x C00041785 pipe pressostat l= 470mm. evo ii
018 C00098754 anti-vibration hose (foam) l= 330
021 C00092173 air trap x oko
022 C00092411 1 x C00094908 hose clamp
023 C00090199 door interlock rold da rst 5usa idc
024 C00045023 filter handle
024 C00045025 filter seal
024 C00045027 pump filter kit
025 C00112504 self cleaning pump 120v 60hz
026 C00074152 bolt m6x30
027 C00074151 rubber bush - motor mount
028 C00074153 spacer motor support l= 187 mm
030 C00040932 self locking nut m6
031 C00090196 motor ceset mcc61 usa 6kg
031 C00145001 1 x C00196554 carbon brush motor ceset eame
032 C00110422 hole for heating element
033 C00091054 coil to protect module 2002
034 C00143951 eeprom evoi awd129na sw
035 C00109898 module (less eeprom) wd usa mdl
036 C00066292 insulated tweezers
036 C00095669 1 x C00145046 hardware key mk1 n1040317
