GB
5
Technical data
Model
IWDC 7085
Dimensions
width 59.5 cm
height 85 cm
depth 53,5 cm
Capacity
from 1 to 7 kg for the wash programme;
from 1 to 5 kg for the drying programme
Electrical
connections
please refer to the technical data plate fixed
to the machine
Water con-
nections
maximum pressure 1 MPa (10 bar)
minimum pressure 0.05 MPa (0.5 bar)
drum capacity 52 litres
Spin speed
up to 800 rotations per minute
Energy rated
programmes
according to
regulation
EN 50229
Wash: programme 2; temperature 60°C;
run with a load of 7 kg.
Drying: first drying cycle performed with a 2 kg
load and the DRYING knob on the
setting;
Second drying cycle performed with a 5 kg load
and the DRYING knob on the
setting.
This appliance conforms to the following EC
Directives:
- 89/336/EEC dated 03/05/89 (Electro-
magnetic Compatibility) and subsequent
modifications
- 2002/96/EC
- 2006/95/EC Low Voltage)
