REGISTERING REMOTE CONTROLS
Controlling the ST-01RL with any channel from any remote control is possible after registering that channel for the given controller.
Our controllers allow for two methods of entering the programming mode:
1.
Each time after connecting to mains, the controller will enter the programming mode for 10 seconds.
2.
The other option is to enter the programming mode with a previously registered remote control.
After the controller is received from the manufacturer or if the previous remote control is lost, a new remote can be registered as follows:
Turn on the remote control and select the channel you wish to register.
Connect the controller to the mains: 230 VAC. Within 10 seconds from connecting the mains:
-
press the ▲ and ▼ buttons at the same time for remotes: PIL-01/04NS, PIL-01/05/09/19DL, PIL-01/05/09/19PM, PIL-19/99PMT,
PIL-19/99DLT, PIL-19/99MMT or
-
press the "1" and "2" buttons at the same time for PIL-02XB or
-
press the "C” and "D" buttons at the same time for PIL-04XB or
-
press the Programming button for PIL-01PT
The drive connected to the controller will make an up and down motion. Within the next 10 seconds register the channel:
-
for remotes PIL-01/04NS, PIL-01/05/09/19DL, PIL-01/05/09/19PM, PIL-19/99PMT, PIL-19/99DLT, PIL-19/99MMT press the ▲
button for the channel you wish to register,
-
for remotes PIL-02XB, PIL-04XB press the button of the channel you wish to register,
-
for remote PIL-01PT press the connected blind switch
The registration will be confirmed by a short up-down movement.
WARNING: The procedure will erase all previously registered channels from the memory of the controller.
This will allow to register a remote control with a controller without another registered remote control (new controller or lost/stolen remote).
WARNING: In order to be able to easily change channel numbers for any controller in the future, each of them should have been assigned an
individual channel number. This way you will be able to program it without disconnecting power from other controllers.
If a remote control has already been registered, subsequent channels of the same or another remote must be registered without disconnecting
from the mains. Switch the ST-01RL controller into programming mode with a previously registered remote control.
To do this, for remotes PIL-01/04NS, PIL-01/05/09/19DL, PIL-01/05/09/19PM, PIL-19/99PMT, PIL-19/99DLT, PIL-19/99MMT
press the ▲ and ▼ buttons at the same time. The roller blind will move up and down. Then it will perform a series of up and down motions,
the number of which will match the number of channels that have been programmed. The drive will remain in programming mode for the next
10 seconds. During that time, in order to register a new channel of the same or another remote, select the desired channel on the remote and
press the ▲ button (for remotes PIL-01/04NS, PIL-01/05/09/19DL, PIL-01/05/09/19PM, PIL-19/99PMT, PIL-19/99DLT, PIL-
19/99MMT).
For remote PIL-02XB press the "1" and "2" buttons at the same time, and for remote PIL-04XB press the "C" and "D" buttons at the same
time. The roller blind will move up and down. Then press an already registered button on that remote. The roller will move up and down again
and then make a series of short up and down motions (in the number equal to the number of programmed channels). The drive will remain in
programming mode for the next 10 seconds. During that time, in order to register a new channel of the same or another remote, press the
desired channel (button) on the remote (for remote PIL-02XB/PIL-04XB).
This way you can register any channel to any controller, but only if you have a previously registered remote control.
WARNING: After power supply interruption, the controller will be ready for operation after ca. 10 seconds.
DELETING STORED CHANNELS: (for PIL-01/04NS, PIL-01/05/09/19DL, PIL-01/05/09/19PM, PIL-19/99PMT, PIL-19/99DLT,
PIL-19/99MMT)
Press ▲ and ▼ at the same time for the selected channel of the registered remote control to delete the stored channels.
The roller shutter connected to the controller will move up and down several times. Press ▲ and ▼ at the same time. The roller shutter will
move up and down once. All channels, except for the channel of the remote used in the procedure, will be deleted.
CHANGING ROLLER BLIND MOVEMENT DIRECTION: (for remotes: PIL-01/04NS, PIL-01/05/09/19DL, PIL-01/05/09/19PM,
PIL-19/99PMT, PIL-19/99DLT, PIL-19/99MMT)
If you need to invert the movement of the roller blind (roller blind movement direction does not match the directions on the remote control), you
must enter programming mode by pressing the ▲ and ▼ button (with a previously registered remote) and then press the STOP button on the
same remote control.
Warning - for safety reasons and due to the possibility of damaging the device with static electricity, controller
programming and registered code deletion should be performed on a workbench with appropriate safety and protective
measures in place against electric shock and static electricity.
