2. Insert cross bar into ‘A’ frames and
align the holes to allow the bolts to
pass through. Attach using nut and
washer then fasten the nut with the
appropriate tools [Figure 2]. (Tools
not supplied).
3. Press both red buttons on the rear
tubular legs and slide them down to
open the frame as shown [Figure 3].
4. To insert the castors turn the frame
upside down. Insert the four castors
into the holes provided in the plastic
bases [Figure 4].
5. Hook the seat onto the seat support
located on the top of the frame.
(Ensure that the two female slots of
the seat support are aligned with the
corresponding male slots located on
seat) [Figure 5].
Figure 2
Figure 3
Figure 4
Figure 5
4
