Figure 10
Figure 11
Figure 12
Figure 13
10. Position the footplate into the correct
height slots for your child [Figure 10].
11. Position cover onto seat body and
allign so that holes are accessible
[Figure 11].
12. Insert each harness part into the
alligning holes, push through until
the end plastic clip protrudes out
the back of the seat [Figure 12].
13. Make sure harness is fully assembled.
Check the hardware clicks together
[Figure 13].
6
