Infasecure CS6010 - Using Lap-Sash Seat Belt

BOOSTER
WITH LAP-SASH SEAT BELT
Remove the seat belt slack by rst pulling on the lap
belt in the direction of arrow 1 (refer gure 1) then pull
the sash belt in the direction of arrow 2. Ensuring the
lap portion is positioned under the armrests and over
the child’s thighs.
The shoulder strap passes diagonally across the
child’s chest and depending on your child’s height
passes either under the headrest for a smaller child
(refer Figure 3) or above the headrest for a larger child
(refer Figure 4).
USING LAP-SASH SEAT BELT
SMALLER
CHILD
Figure 3 Figure 4
LARGER
CHILD
1
2
Figure 2
Step 4:
DO NOT LEAVE CHILDREN
UNATTENDED IN THE CAR.
WARNING
!
SAFETY WARNING
OR
A sash belt under the
arm or behind the back
is dangerous
WARNING
!
Buckle &
Tongue Assembly
Buckle &
Tongue Assembly
8
