// USER GUIDE_EN 3
ABOUT THE BATTERY CHARGER
1) The LCD710 is designed for charging 12V/24V lead-
acid and 12V lithium-ion batteries (LiFePO4).
2) Built-in intelligent microprocessor makes charging faster, easier and safer.
3) This charger has safety features, including spark proof, protection
for reverse polarity, short circuit, overheat and overcharge.
4) When starting, the battery voltage type is 12V by default. The user can
select battery voltage type by pressing “12V/24V” button in standby.
5) When starting, the charger works for STD battery type by default. The user can
select battery type include STD, COLD/AGM, CAL, LiFePO4(only for 12V battery)
by pressing and holding “FUNCTION/TYPE” button for 3 seconds in standby.
6) When the charger is powered on, it enters the standby mode
by default. The user can select functions including CHARGE,
SUPPLY, REPAIR by pressing “FUNCTION/TYPE” button.
TECHNICAL SPECIFICATIONS
AC-input: 220-240V AC, 50-60Hz, 140W
DC-output: 12V DC, 7A; 24V DC, 3.5A; Temperature Controlled.
Efficiency: 85 % Approx
Charger Type: 8 steps, Full-automatic Charging Cycle
Battery Type: All Types of 12V and 24V Lead-acid Batteries
Housing Protection: IP65
Ambient Temperature: 0 °C ~ +40 °C
Accessories Included: Battery Clamps
8) To reduce risk of electric shock, unplug charger from outlet
before attempting any maintenance or cleaning.
9) Operate with caution if the charger has received direct hit of force or
been dropped. Have it checked and repaired if damaged.
10) Any repair must be carried out by the manufacturer or an
authorized repair agent in order to avoid danger.
