7. Place the lower door on a smooth surface
with its panel upwards. Loose screws ③ ,
detach part ② and part ①. Turn part ① by 180°
and then install part ① and part ② to
corresponding position on left side together
with screws ③.
8. Change screw hole covers on middle cover
plate from left to right(as shown in figure
below).
9. Place refrigeration flat, remove part ② and
then loose screws ④. Remove part ①and part
③.
10. Screw out lower hinge. Change it to the
near hole site, and then screw up and mount
washer.
11. Just remount to the step 9. Change part ①
and part ② to left and then fix them with
screws ④. Change part ③ to right, and install it.
1
2
3
Lower hinge part (right)
Leg front (right)
Leg front (left)
Self-tapping-screws
Step 7 Step 8
Step 9
Lower hinge part (left)
Step 11
-50-
