Remove all packing material and accessories.
Examine the oven for any damage such as
dents or broken door. Do not install if oven is
damaged.
Countertop Installation
Cabinet: Remove any protective film found
on the microwave oven cabinet surface.
Do not remove the light brown Mica cover
that is attached to the oven cavity to
protect the magnetron.
Installation
side must be open.
1. Select a level surface that provide
enough open space for the intake
and/or outlet vents .
A 10-cm spacing should be kept between
the appliance and right and back walls,
and a 30-cm spacing kept on the top.Never dismantle
the applicance's feet ,nor block the air intake and
exhaust opening.
can damage the oven.
) Place the oven as far away from
radios and TV as possible.
Operation of microwave oven may
cause interference to your radio or TV
reception.
outlet. Be sure the voltage and the
frequency is the same as the vol
tage
and the frequency on the rating label.
1) Blocking the intake and/or outlet openings
2
3 Plug your oven into a standard household
)
Fig 1
( )Fig 1ure
30cm
OPEN
eftThe l
12 inch( )
4.0 inch(10cm)
4.0 inch(10cm)
4） cirtcele,tekcos gulp eh T :gninraW
appliances or the appliance which are
liable effected by heat and moisture should
be kept away from any vents on the oven.
The appliance can be installed with a degree
of overlap(Figure 2).The maximum overlap
height is two layers.
Fig 2
External Equipotential
Earthing Terminal (export only)
Equipment has secondary earthing
terminal. Terminal provides external
earthing connection used in addition
to earthing prong on plug. Located
on outside of oven back, terminal is
marked with symbol shown below.
