Infiniton WSD-B695 - Built-In Installation

Appendix
Self-tapping
screws(ST4*12)
Self-tapping
screws(M5*12)
Hinges
Counter magnet Spacer
Fixed position
paper
Tool
Screw driver
Automatic driver Ruler Pencil
Built-in installation
Install Steps
Overview
1
825mm
600mm
540mm
595mm
152.5mm
580mm
825mm
Preparation and assembly of the door
The door is open from right to leftThe door is open from left to right
10
31
MAINTENANCES
