- CONTENTS -
SPECIFICATIONS ………………………………………..1
PACKING……………………………………………..…....2
CONTROL/INSTALLATION INSTRUCTIONS….……....3
CONTROL/INSTALLATION DRAWINGS……….………4
BASIC TROUBLESHOOTING……………………………5
DISASSEMBLY INSTRUCTIONS………………………..6
EXPLODED VIEW/PARTS LIST…….….….…………....7
AMPLIFIER BLOCK DIAGRAM…………………….……8
ELECTRICAL PARTS LIST ..……….……….…….…….9
P.C.B. DRAWINGS….………………………..…….……14
IC/TRANSISTOR PINOUTS..………………..….….…..20
SCHEMATICS……………..……………….………..…...23
Kappa One Specifications
Output Power: 500W RMS x 1 channels @ 4 ohms; ≤1% THD + N
(14.4V supply) 800W RMS x 1 channels @ 2 ohms; ≤1% THD + N
Total Peak Power 1600W
Signal-to-noise ratio: 85dBA (reference 1W into 4 ohms)
109dBA (reference rated power into 4 ohms)
Frequency response: 20Hz – 320Hz (–3dB)
THD+N 1KHz LPF=22KHz ≤0.05% (rated power @ 4 ohms)
Input Impedance >20K ohms
Maximum input signal: 6.0V
Maximum sensitivity: 200mV
Bass Boost @ 20-100Hz 0-12dB
DC Offset <30mV
Idle Current @ 4 ohms 1.6A
Max Current Draw 76A
Remote Operating Voltages OFF 4V
Circuit Protection Temperature (80C), Short circuit, over/under voltage
Operating voltage range (8-16V)
Dimensions: 13 x 7 x 1 ¾” (329 x 179 x 44mm)
Fuses: (3) x 40A
Infinity Systems continually strives to update and improve existing products, as well as create new ones. The specifications and
details in this and related JBL publications are therefore subject to change without notice.
