Front-side view:
Guidinglines that indicate the width and the
frontend of the vehicle are displayed on the
monitor.
The front-of-vehicleline
j
1shows the front part
of the vehicle.
The side-of-vehicle line
j
2shows the vehicle
width including the outside mirrors.
The extensions
j
3ofboth the front
j
1and side
j
2lines are shown with agreen dotted line.
Thecorner sensorindicator
j
4willappear when
acorner of the vehicle moves closer to an ob-
ject.
DIFFERENCEBETWEEN PREDICTIVE
AND ACTUAL DISTANCES
The displayed guidelines and their locationson
the ground are forapproximate referenceonly.
Objects on uphillordownhillsurfacesorpro-
jectingobjects will be actually located at dis-
tances different from those displayed in the
monitorrelative to the guidelines (refer to illus-
trations). When in doubt, turn around and view
the objectsas youare reversing, orparkand exit
the vehicle to view the positioning ofobjects be-
hindthe vehicle.
Reversing up asteep slope
When reversingthe vehicle up ahill, the dis-
tanceguide lines and the vehicle width guide
linesare shown closer than the actual distance.
Note that any object on the hillisviewed in the
monitorfurther than it appears.
SAA1842Z
Left-Hand Drive (LHD) models*
NAA1675
4-24 Displayscreen, heater and air conditioner,and audio system
