Drain plug location
Engine oiland filter
1. Remove the engine undershield.
2. Placealargedrain pan under the drain plug.
3. Remove the drain plug
j
1with awrench.
4. Remove theoil fillercapandcompletely drain
the oil.
Waste oil must be disposed of properly.
Checkyour local regulations.
5. (Perform steps4to 8onlywhen the engine
oilfilter change is needed.)
Loosen the oil filter with an oil filter wrench.
6. Remove the oil filter by turning itbyhand.
7. Wipe the engine oil filter mounting surface
with aclean cloth.
Be sure to remove any old gasketremaining
on the mounting surface.
8. Apply new engine oil to the gasketofanew
oil filter.
9. Screwinthe oil filter clockwiseuntil aslight
resistanceisfelt, and then tighten an addi-
tional 2/3 of aturn to secure the oil filter.
Engine oil filter tightening torque:
1.6Land 2.0L petrol engine
25 N•m
(2.6kg-m, 19 ft-lb)
1.5L diesel engine
14 N•m
(1.4 kg-m, 10 ft-lb)
2.2L diesel engine
25 N•m
(2.6kg-m, 19 ft-lb)
10. Cleanand reinstallthe drain plug and new
washer.Securely tightenthe drainplug with
awrench. Do not useexcessive force.
Drainplug tightening torque:
1.6L and 2.0L petrol engine
30 N•m
(3.10 kg-m, 22 ft-lb)
1.5L diesel engine
20 N•m
(2.1 kg-m, 15 ft-lb)
2.2L diesel engine
30 N•m
(3.1 kg-m, 22 ft-lb)
NDI1622
1.6L and2.0L petrol engine
NDI1064
1.5L dieselengine
JVM0427XZ
2.2L diesel engine
8-10 Maintenanceand do-it-yourself
