Harman Consumer Group,Inc.,250 Crossways Park Drive,Woodbury,NY 11797 USA
www.infinitysystems.com
© 2008 Harman International Industries,Incorporated.All rights reserved.• Part No.REFX60SUBOM 8/08
Infinity is a trademark of Harman International Industries,Incorporated,registered in the United States and/or other countries.
SPECIFICATIONS
860w 1060w 1062w 1260w 1262w
8" (200mm) 10" (250mm) 10" (250mm) 12" (300mm) 12" (300mm)
Sensitivity
@ 2.83V/1m: 91dB 91dB 94dB (2 ohms) 93dB 96dB (2 ohms)
Power Handling (RMS): 250W 275W 275W 300W 300W
Power Handling (Peak): 1000W 1100W 1100W 1200W 1200W
Frequency Response: 30Hz – 400Hz 25Hz – 400Hz 25Hz – 400Hz 23Hz – 400Hz 23Hz – 400Hz
Impedance: 4 ohms 4 ohms 2 or 8 ohms 4 ohms 2 or 8 ohms
Voice-Coil Diameter: 2" (51mm) 2" (51mm) 2" (51mm) 2" (51mm) 2" (51mm)
Mounting Depth: 5-3/16" (131mm) 5-7/8" (149mm) 5-7/8" (149mm) 6-7/16" (162mm) 6-7/16" (162mm)
Overall Diameter: 8-7/16" (214mm) 10-7/16" (264mm) 10-7/16" (264mm) 12-3/8" (314mm) 12-3/8" (314mm)
Cutout Diameter: 7-5/16" (186mm) 9-1/4" (234mm) 9-1/4" (234mm) 11-1/8" (282mm) 11-1/8" (282mm)
A valid serial number is required for warranty coverage.
Features,specifications and appearance are subject to change without notice.
These products are designed for mobile applications and are not intended for connection to the mains.
Declaration of Conformity
We, Harman Consumer Group, Inc.
2, route de Tours
72500 Château du Loir
France
declare in own responsibility that the products described
in this owner’s manual are in compliance with technical
standards:
EN 61000-6-3:2001
EN 61000-6-1:2001
Klaus Lebherz
Harman Consumer Group, Inc.
Château du Loir, France 8/08
ENGLISH
38545_Ref_Inf_woofer_860W_OM 22/08/08 9:29 Side 5
