Infinity TSS-Sub500 - Electrical Parts List

TSS-Sub500 (120v) Electrical Parts List
Part Number
Description
Qt
y
Reference Designator
PREAMP PCB
Resistors
110-16102j26 Resistor 1K 1/6W ±5% CF 26mm 4
R213,214,215,254
110-16103j26 Resistor 10K 1/6W ±5% CF 26mm 13
R212,216,217,220,221,222,225,228,226,232,
235,240,248
110-16104j26 Resistor 100K 1/6W ±5% CF 26mm 2
R231,266
110-16105j26 Resistor 1M 1/6W ±5% CF 26mm 1
R259
110-16122j26 Resistor 1.2K 1/6W ±5% CF 26mm 1
R264
110-16124j26 Resistor 120K 1/6W ±5% CF 26mm 1
R233
110-16151j26 Resistor 150Ω 1/6W ±5% CF 26mm 1
R253
110-16153j26 Resistor 15K 1/6W ±5% CF 26mm 1
R234
110-16154j26 Resistor 150K 1/6W ±5% CF 26mm 1
R252
110-16183j26 Resistor 18K 1/6W ±5% CF 26mm 2
R262,227
110-16205j26 Resistor 2M 1/6W ±5% CF 26mm 1
R257
110-16223j26 Resistor 22K 1/6W ±5% CF 26mm 4
R238,247,250,255
110-16273j26 Resistor 27K 1/6W ±5% CF 26mm 2
R223,237
110-16333j26 Resistor 33K 1/6W ±5% CF 26mm 1
R249
110-16472j26 Resistor 4.7K 1/6W ±5% CF 26mm 2
R258,260
110-16473j26 Resistor 47K 1/6W ±5% CF 26mm 2
R219,251
110-16512j26 Resistor 5.1K 1/6W ±5% CF 26mm 3
R211,229 ,230
110-16513j26 Resistor 51K 1/6W ±5% CF 26mm 1
R224
115-h503a104 variable Resistor D16 50K/1 A LEVEL 1
VR201
Capacitors
130-2b221k503 disc Capacitor 220P 50V ± 10% 9
C207,208,210,211,212,214,220,230,249
130-3f104z503 disc Capacitor 0.1U 50V +80/-20% 7
C232,242,244,245,246,252,254
130-sl470k503 disc Capacitor 47P 50V ± 10% 1
C229
132-103j503 electrolytic 0.01U 50V ± 5% 2
C223,224
132-104j503 electrolytic 0.1U 50V ± 5% 3
C218,221,222
132-223ja03 electrolytic 0.22uF 100V ± 5% 1
C215
132-473j503 electrolytic 0.047U 50V ± 5% 2
C216,217
135-3105m50 electrolytic 1U 50V ± 20% 1
C228
135-3106m50 electrolytic 10uF 50V ± 20% 8
C206,213,219,231,241,243,251,253
135-3107m16 electrolytic 100uF 16V ± 20% 2
C233,234
135-3226m50 electrolytic 22U 50V ± 20% 1
C225
Semiconductors
192-027c1815gr Transistor 2SC1815GR NPN 3
Q201,206,207
197-031n4148 diode 100mA 75V SIGNAL 1N4148 ROHM 7
D201,202,207,208,211,212,214
199-15000335 zener diode 3.3V 1/2W 52mm 1
D213
190-06m4558d I.C OPA 4558D DUAL OP-AMP 1
U203
190-16t1074cn I .C TL074cm QUAD OP-AMP 2
U201,202
195-10204hgw LED 204HGW 3c 1
D209
Miscellaneous
162-50159201 WIRE ASS'Y 2PIN 150mm 1
for D209
174-0rca326p JACK RCA-326 1
JK202
POWER/MAIN PCB
Resistors
110-14472j26 Resistor 4.7K 1/4W ±5% 26mm 2
R147,150
110-14681j26 Resistor 680Ω 1/4W ±5% 26mm 2
R148,151
20
TSS-Sub500
