InFocus LitePro 720 - Page 55

52
Appendix
Remote Control
Battery Two (2) AAA alkaline cells
Input Power Requirements
100-120/220-240V, 5.0/3.0A, 50/60 Hz.
Video Audio Input
Input Impedance 5K ohm DC coupled
Maximum Input Voltage (L
IN
+ R
IN
)
PEAK
< 4.5 V for THD ≤ 0.3%
L
IN
or R
IN
< 2.0 Vrms for THD ≤ 0.3%
Sensitivity 100 mV at 1 KHz for 88 dB SPL at 1 meter
Connector Type RCA jack
CableWizard Audio Input
Input Impedance 10K ohm nominal, AC coupled
Maximum Input Voltage (L
IN
+ R
IN
)
PEAK
< 4.5 V for THD ≤ 0.3%
L
IN
or R
IN
< 2.0 Vrms for THD ≤ 0.3%
Sensitivity 100 mV at 1 KHz for 88 dB SPL at 1 meter
Connector Type 3.5 mm (1/8 inch) stereo phone jack
