TECHNICAL CHARACTERISTICS
General specifications
7 protected outlets with child safety (Shuko outlet)
Reset circuit breaker.
Non-flammable plastic casing. Wall attachment possible
Dimensions ( w x d x h): 120 x 270 x 40 mm
Weight : 670 g
Cable length: 1.8 m.
Conform with the CE standard & PCT standard
Lifetime warranty
Electrical specifications
Nominal voltage 200 - 250 V AC
Peak voltage 775 Volts
Maximum power 10 A
Surge energy rating 3 x 238 Joules (H-N, H-G, N-G)
Peak current 8/20 µs 19 500 A (6500 A x 3 lines)
Response time < 1 nanosecond
EMI/RFI filter
Frequency range 150 kHz ~ 100 MHz
Attenuation up to 40 dB
Light indicators
Orange light on Protection device active
Green light on Power OK
Phone - fax - modem -XDSL protection
Peak voltage 395 Volts
Maximum surge energy 320 Joules
Satellite connection protection
Protection < 75 V
Attenuation < 0.1 dB
Environment
Temperature 0° to 40° Celsius
Relative humidity 0° to 95 % relative humidity
PFS 7 TCGE
1
2
4
3
5
6
8
9
