Page #1 background image

Loading...

Page #1 background image

80442775

Revision E

July 2012

Save These Instructions

Nirvana Cycling Refrigerated Dryer

Models 200-400

Operator’s Manual

Manual Del Operador

ES

Manual do Operador

PT

Manuel De L’opérateur

FR

Operator’s Manual

EN

ENGLISH

PORTUGUESE

PRINT LANGUAGE

FRENCH

SPANISH

Table of Contents

Questions and Answers:

D
Devon MoralesAug 9, 2025
Why is there high pressure drop across my Ingersoll-Rand NVC 400?
- M
  Monica PriceAug 10, 2025
  A high pressure drop across the dryer can occur for several reasons: * Ensure that the inlet and outlet valves are completely open. If not, open them. * The inlet and outlet filters might be blocked. Change the filter elements. * A stuck compressor relay or contactor can cause this issue. Replace the relay or contactor. * A bad microprocessor control relay can also be the reason. Replace the relay. * Inspect the probe and check readings against an independent source (e.g., temperature analyzer/pyrometer/ice bath) both in the exchanger well and to ambient. If the issue persists, turn the dryer off and consult your local distributor for further assistance.
T
Timothy RosalesAug 14, 2025
What to do if my Ingersoll-Rand NVC 400 Dryer controller display malfunctions?
- B
  Blake BrownAug 14, 2025
  If the controller display is malfunctioning, try these steps: * Check the fuses and replace them if they are blown. * Inspect the probe cable and terminal connection. Replace the probe if necessary. * Ensure the probe is completely in the thermal well and check readings against an independent source (e.g., temperature analyzer/pyrometer/ice bath) both in the temperature well and to ambient. * Replace the probe if it's defective. * Inspect the transducer cable and terminal connection. If necessary, replace the transducer.
A
Anthony BurgessAug 17, 2025
Why is there air bleed from the condensate drain outlet port of my Ingersoll-Rand Dryer (Optional- No Air Loss Drain)?
- C
  Casey JohnsonAug 18, 2025
  Air bleeding from the condensate drain outlet port could be due to debris trapped under the seal or damage to the seal. To resolve this: * Press and hold the test button to clear any debris (this will open the drain valve). * If the problem persists, replace the seal with a Service Kit.
W
William JohnsonAug 22, 2025
What to do if the condensate drain does not fire in my Ingersoll-Rand NVC 400?
- J
  Joan MurrayAug 22, 2025
  If the condensate drain isn't firing, consider the following: * Check that the installation follows the manual's guidelines and revise it if needed. * If the inlet/outlet pipe's internal diameter is too small, replace it with larger diameter piping. * Reduce the number of bends and elbows in the inlet/outlet pipe work. * Reconfigure the condensate piping if the outlet pipe is too long or high. * If there's more than one condensate source connected, reroute the condensate to eliminate the secondary path and install check valves as required.
S
Scott ClarkAug 27, 2025
Why does the condensate drain bowl not fill with condensate in my Ingersoll-Rand NVC 400, and the drain does not seem to work due to air locking (Optional-No Air Loss Drain)?
- M
  Marcia BridgesAug 27, 2025
  If the condensate drain bowl doesn't fill and air locking seems to be the issue: * If the bottom inlet is used, ensure the top port is used as an air bleed. * Connect the top inlet to a higher point in the system; this will function as an air bleed for the drain.
M
Michael CarterAug 30, 2025
What to do if the condensate drain LED is off on my Ingersoll-Rand NVC 400 Dryer (Optional-No Air Loss Drain)?
- E
  Elizabeth MitchellAug 31, 2025
  If the condensate drain LED is off, check the power supply. Press the test button for a minimum of 2 seconds and observe. Locate and eliminate any supply fault.

Ingersoll-Rand NVC 400 Specifications

General

Maximum Operating Pressure	150 psig
Maximum Working Pressure	150 psig
Refrigerant	R-134a
Capacity	400 CFM
Frequency	60 Hz
Maximum Inlet Temperature	120 °F
Ambient Temperature Range	110 °F
Airflow Capacity at 100 psig	400 CFM
Pressure Dew Point	50 °F

Summary

Receiving, Inspection, and General Safety

6.0 Safety and Operation Precautions

Lists essential safety rules and precautions for operating and maintaining the air dryer.

Safety Alert Symbol Definitions

Explains the meaning of WARNING, CAUTION, and NOTICE symbols used in the manual.

Critical Safety Warnings

Electrical Connection Box High Voltage Warning

Warns about high voltage in the electrical connection box and the need for power lockout.

Fuse Safety and Power Disconnection Advice

Emphasizes that fuses do not disconnect power and advises disconnecting all sources before service.

Fan Automatic Start and Refrigerant Pressure Warnings

Alerts users about potential fan start-up and high refrigerant pressure hazards.

Principles of Operation: Dryer Systems

7.1 Introduction to Dryer Operation

7.2 Compressed Air System

7.3 Moisture Removal System

Details how condensate is removed from the air stream using a separator and drain.

7.3.1 Standard Solenoid Drain Operation

Explains the operation and settings for the standard timed electric solenoid drain.

Principles of Operation: Systems and Controls

7.3.2 Optional No-Air-Loss Drain

7.4 Refrigeration System

7.5 Thermal Mass Circulating System

7.6 Dryer Control System

Dryer Control Interface and Setpoints

7.6.1 Basic User Interface Overview

Provides an overview of the controller's keypad functions and display.

7.6.2 Exchanger Temperature Setpoint and Alarms

Explains how to configure the exchanger temperature set point and associated alarms.

Dryer Alarms, Messages, and Start Modes

7.6.3 Adjusting Temperature Set Points

Describes the procedure for adjusting the exchanger temperature set point using the controller.

7.6.4 Dryer Alarms and Functions

Lists and explains the critical alarms and their corresponding LED indicators and functions.

7.6.5 Dryer Alert Messages

7.6.6 Dryer Start Modes

Installation and Initial Start-up

8.1 Dryer Location and Mounting

8.2 Piping and Valve Installation

8.3 Air Filtration Recommendations

Electrical Connections and Start-up Sequence

8.4 Electrical Connection

8.5 Initial Start-up Procedure

8.5.1 Start-up Sequence

Scheduled Maintenance

9.2 Refrigerant Condenser Maintenance

9.3 Condensate Discharge System Maintenance

9.3.1 Standard Solenoid Drain Maintenance

Filter and Drain Maintenance

9.3.2 Optional No-Air-Loss Drain Maintenance

9.4 Panel Filter Element Replacement

9.5 Pre-Filters and Post-Filters Maintenance

Dryer Troubleshooting

10.1 Troubleshooting Introduction and Warnings

Introduces the guide for identifying and resolving dryer malfunctions, including safety.

10.2 Problem/Action Guide - Common Issues

Presents common problems, symptoms, causes, and corrective actions for dryer issues.

Continued Dryer Troubleshooting

10.2 Problem/Action Guide - Continued Issues

Continues the table of common problems, symptoms, causes, and corrective actions for the dryer.

Condensate Drain Troubleshooting

10.2 Problem/Action Guide - Drain Issues

Lists troubleshooting steps for condensate drain issues and air locking problems.
