Ingersoll-Rand NVC 300

Questions and Answers

C
Courtney FisherAug 9, 2025
Why is there high pressure drop across my Ingersoll-Rand NVC 300?
- S
  shawkinsAug 9, 2025
  A high pressure drop across the dryer can occur for several reasons: * Ensure that the inlet and outlet valves are completely open. If not, open them. * The inlet and outlet filters might be blocked. Change the filter elements. * A stuck compressor relay or contactor can cause this issue. Replace the relay or contactor. * A bad microprocessor control relay can also be the reason. Replace the relay. * Inspect the probe and check readings against an independent source (e.g., temperature analyzer/pyrometer/ice bath) both in the exchanger well and to ambient. If the issue persists, turn the dryer off and consult your local distributor for further assistance.
T
Timothy SimsAug 13, 2025
What to do if my Ingersoll-Rand NVC 300 controller display malfunctions?
- C
  Chad BarronAug 13, 2025
  If the controller display is malfunctioning, try these steps: * Check the fuses and replace them if they are blown. * Inspect the probe cable and terminal connection. Replace the probe if necessary. * Ensure the probe is completely in the thermal well and check readings against an independent source (e.g., temperature analyzer/pyrometer/ice bath) both in the temperature well and to ambient. * Replace the probe if it's defective. * Inspect the transducer cable and terminal connection. If necessary, replace the transducer.
A
Arthur ValdezAug 18, 2025
Why is there air bleed from the condensate drain outlet port of my Ingersoll-Rand NVC 300 Dryer (Optional- No Air Loss Drain)?
- J
  jacob47Aug 18, 2025
  Air bleeding from the condensate drain outlet port could be due to debris trapped under the seal or damage to the seal. To resolve this: * Press and hold the test button to clear any debris (this will open the drain valve). * If the problem persists, replace the seal with a Service Kit.
S
Samuel ArnoldAug 22, 2025
What to do if the condensate drain does not fire in my Ingersoll-Rand NVC 300 Dryer?
- K
  Keith PenningtonAug 22, 2025
  If the condensate drain isn't firing, consider the following: * Check that the installation follows the manual's guidelines and revise it if needed. * If the inlet/outlet pipe's internal diameter is too small, replace it with larger diameter piping. * Reduce the number of bends and elbows in the inlet/outlet pipe work. * Reconfigure the condensate piping if the outlet pipe is too long or high. * If there's more than one condensate source connected, reroute the condensate to eliminate the secondary path and install check valves as required.
C
Cheryl PerezAug 27, 2025
Why does the condensate drain bowl not fill with condensate in my Ingersoll-Rand NVC 300 Dryer, and the drain does not seem to work due to air locking (Optional-No Air Loss Drain)?
- J
  Jasmine KingAug 27, 2025
  If the condensate drain bowl doesn't fill and air locking seems to be the issue: * If the bottom inlet is used, ensure the top port is used as an air bleed. * Connect the top inlet to a higher point in the system; this will function as an air bleed for the drain.
C
Christina SmithAug 30, 2025
What to do if the condensate drain LED is off on my Ingersoll-Rand Dryer (Optional-No Air Loss Drain)?
- G
  Gregory EllisonAug 30, 2025
  If the condensate drain LED is off, check the power supply. Press the test button for a minimum of 2 seconds and observe. Locate and eliminate any supply fault.
S
Stephen RogersNov 4, 2025
What to do if there is moisture downstream from my Ingersoll-Rand NVC 300 Dryer?
- J
  Jeremiah LarsonNov 4, 2025
  If you notice moisture downstream, here are some things you can check: * Replace the service unit, as the condensate drain failure may be caused by a defective service unit. * Check the inlet and outlet pressure and system design capacity to correct the cause of excessive flow. * Ensure the bypass valve is closed. * Inspect the power supply, fuses, and circuit breakers. * Clean the condenser. * If the suction pressure gauge reads 0 psig, turn the dryer off and contact your distributor. * Make sure the ambient temperature is below 113°F. * Check the chiller temperature. * Check the MAIN CONTROL fuse. * Replace the compressor relay if it is bad. * Check for loose wire connections at the contactor or loss of power at the control board. * If necessary, replace the defe...
