Signaling 11
Installation and Programming manual
5 seconds after which, the LEDs emit slow blinks (duration of 1
second) which signal the type of fault or tamper.
If several conditions are detected simultaneously, both LEDs are
capable of signalling the events consecutively.
The following table shows the various event types and how they are
signalled on the LEDs (the number of slow blinks which signal the
type of event concerned and the related Programming-menu option
which will allow you to enable/disable the respective signalling
capacities.
Fault signalling will stop automatically when the cause of the fault
clears.
Tamper memory signalling will clear only after two consecutive
alarm events.
Table 6: Fault and tamper signaling
LED
Number of
blinks
Event
Menu option
Number Option
STATUS
1
Faults
Horn fault 13
2 Low battery 14
3 Inefficient battery 14
PRG
1
Tamper memory
Power failure 9
2 Open casing 10
3 Foam tamper 11
4 Blow torch tamper 12
