 “BR”; the detector signals alarm status when the temperature within the protected environment

exceeds 72° or when it senses a rapid temperature rise.

Note

The operating modes of the “A2S” and “BR” are not certified.

ED300

Optical-heat detector with heat sensitive element and optical smoke chamber. The combination of

values provides (in accordance with the operating mode selected via the control panel) high immu-

nity to nuisance alarms and an exceptionally sensitive detector which is capable of swift response to

fires characterized by low smoke emission.

Operating mode

Mode

The operating modes, programmable via the control panel are:

 “PLUS” (pre-set); the detector signals alarm status when smoke in the protected environment

exceeds the programmed threshold (programmed as described for the ED100 model) or when

the temperature within the protected environment exceeds the programmed threshold (pro-

grammed as described for the ED200 model). Furthermore, in the event of a rise in temperature

within the protected environment, the sensitivity of the smoke chamber will be increased. This

operating mode, characterized by high sensitivity, allows detection of fires which produce a large

amount of flames but low smoke emission (e.g. combustion of alcohol or similar highly-inflam-

mable products).

 “OR”; the detector signals alarm status when smoke in the protected environment exceeds the

programmed threshold (programmed as described for the ED100 model) or when the tem-

perature within the protected environment exceeds the programmed threshold (programmed as

described for the ED200 model). This operating mode, characterized by medium-high sensitivity,

allows detection of fires which generate a substantial amount of smoke but low heat emission

(slow burning fires) as well as fires which generate high temperatures and low smoke emission

(chemical products).

 “AND”; the detector signals alarm status when the smoke and temperature in the protected envi-

ronment exceed the programmed thresholds simultaneously (programmed as described for the

ED100 model and ED200 model respectively). This operating mode, characterized by a low sen-

sitivity, lowers the false alarm rate and is useful in applications where either the smoke or heat

values in the protected environment may increase without the risk of fire.

Note

Given the limited response, consider the conditions in the protected environment carefully

before selecting this operating mode.

 “SMOKE”; the detector assumes the characteristics of the ED100 model

 “HEAT”; the detector assumes the characteristics of the ED200 model

LED

The three-colour LED (360° viewing) indicates the detector status.

 Green blinking at 15-second intervals; the detector is in standby status (i.e. operating properly).

 Green On solid; the LED has been activated manually from the control panel. This operation

allows easy identification of the detector.

 Yellow On solid; the detector is in fault status or has detected a short-circuit in the succeeding

wiring section (short-circuit isolator open). Further details regarding the fault can be obtained

through the control panel.

 Red On solid; the detector is in alarm status. Further details regarding the alarm can be obtained

through the control pane

“R” terminal

The detectors have an output (terminal “R”), for the connection of an alarm repeater LED. This LED

will activate in accordance with programming carried out via control panel.

The detector is also capable of discerning whether its repeater LED has been connected. This func-

tion provides indications (on the control panel) regarding the detectors with connected LEDs, and

also fault signals in the event of disconnection.

Description of the parts

A Detector

B Detector notch

C Thermal probe

D Red/yellow/green LED

E Optical chamber

F Technical specifications/serial-number sticker

G Removable serial-number stickers

H Cover removing hooks

I Optical chambre removing hooks

J Base

K Base notch 1

L Base notch 2

M “+” terminal

N “-” terminal

O “R” terminal

P Short-circuit reed

Q Screw locations

Installation

Note

For information regarding device placement, coverage and method of installation, refer to

the established standard regulations and codes relating to Automatic fire-detection

systems.

Enea series detectors are compliant with EN54-7: Smoke detectors – Point detectors using

the scattered light principle, light transmission or ionization (ED100 and ED300 models

only) and EN54-5: Heat detectors – point detectors (forED200 and ED300 models only),

EN54-17 short-circuit isolators.

The detectors are supplied with protective covers which help to protect them against minor damage

and dust contamination which may occur during the installation phase. The covers should not be

removed until the system is ready to start up.

The detectors can be used with one of the following compatible mounting bases:

 EB0010, standard base

 EB0110, standard base with removable address label plate

An example of installation using standard bases is shown opposite.

 EB0020, relay base

 EB0120, relay base with removable address label plate

Appropriate when the detector is to be connected to an intrusion control panel or to a control panel

using 4 wires.

Note

The two removable serial-number stickers should be taken off and one should be attached

to the mounting base and the other to the installation layout.

Once the base is located properly in its placement, place the detector unit onto the base and, with

minimum force, turn it clockwise until the detector notch [B] aligns with the base notch [K] (in order to

attach the detector to the base); turn it still further until notch [B] aligns with the second base notch

[L] (in order to allow the base to engage with the detector contacts).

When installation of all the loop devices is complete, proceed with the addressing phase. Refer to

the respective section in the control panel installation and programming manual.

Using the EDRV2000 driver

The EDRV2000 driver allows you to change the operating parameters of the detectors, check the

contamination level of the smoke chambers and also obtain accurate diagnostic data. It can operate

through the USB port of a computer furnished with the relative software programme, or can function

autonomously by way of the battery housed inside.

Each detector is capable of retaining memory (smoke and/or temperature depending on the model)

of the 5 minutes prior to an alarm. Therefore, if an alarm occurs, it will be possible to obtain infor-

mation regarding the onset of the fire by simply connecting the EDRV2000 driver to the detection

line.

For further information and details regarding use of the EDRV2000 driver, refer to the respective

handbook.

Testing and maintenance

After installation and during periodic maintenance inspections, you must carry out the following ope-

rations on each detector:

Optical smoke detector test; smoke detectors should be tested immediately after installation and

periodically during maintenance inspections in accordance with the established standard regu-

lations and codes in force. To test smoke detectors, use an approved test aerosol strictly in accor-

dance with the accompanying instructions.

Ensure that the smoke inlet ports to the smoke detection chamber are not blocked. Check the con-

tamination level of the smoke detection chamber via the control panel. If the contamination level is

high (above 50%), detach the detector from its mounting base, open the device and, using a small,

soft-bristle brush or hand-held vacuum cleaner remove all dust particles from inside and around the

smoke detection chamber.

Free the protection mesh from all contaminants.

Heat detector test; using a suitable device (e.g. hairdryer), create heat in the vicinity of the detector,

then work through the steps described in the device instruction sheet. During each periodic main-

tenance inspection, ensure that the heat element is intact and that is not obstructed by dust or paint.

If it is, using a small, soft-bristle brush or hand-held vacuum cleaner remove all contaminants.

Technical specifications

Model

ED100 ED200 ED300

Power supply from19 to 30 V

Current draw in standby 200µA

Current draw in alarm 10mA @27,6V

Current draw by the “R” output

(internally limited)

Max 14mA

Dimensions (DxH, standard base

included)

110 x 46 mm 110 x 54 mm

Weight

160g, standard base included

91g, without base

Model

ED100 ED200 ED300

Environmental conditions

Temperature from -5 to +40 °C

Relative humidity ≤ 95 % without condensation

CE mark

0051

INIM Electronics s.r.l.

Via Dei Lavoratori 10 - Fraz. Centobuchi

63076 Monteprandone (AP) - Italy

0051-CPR-1878

EN 54-7:2000 + A1:2002 + A2:2006

EN 54-17:2005

ED100

Intelligent analogue addressable optical smoke detec-

tor with short circuit isolator for fire detecti

on and fire

alarm systems installed in buildings

Essential characteristics Performance

Nominal activatio

n con-

dition/sensitivity, response delay

(response time) and performance

under fire conditions

PASS

Ope

rational reliability PASS

Tolerance to supply voltage PASS

Durability of

operational

reliability:

Temperat

ure resi-

stance

PASS

Vibration resistance PASS

Humidity resistance PASS

Corrosion resistance PASS

Electrical

stability PASS

0051

INIM Electronics s.r.l.

Via Dei Lavoratori 10 - Fraz. Centobuchi

63076 Monteprandone (AP) - Italy

0051-CPR-1877

EN 54-5:2000 + A1:2002

EN 54-17:2005

ED200

Intelligent analogue addressable class P heat detector

with short circuit isolator for fire detection

and fire alarm

systems installed in buildings

Essential characteristics Performance

Nominal activation

con-

dition/sensitivity, response delay

(response time) and performance

under fire conditions

PASS

Opera

tional reliability PASS

Tolerance to supply voltage PASS

Durability of

operational

reliability:

Temperatur

e resi-

stance

PASS

Vibration resistance PASS

Humidity resistance PASS

Corrosion resistance PASS

Electrical s

tability PASS

Detector class (EN54-5): A1R or B

0051

INIM Electronics s.r.l.

Via Dei Lavoratori 10 - Fraz. Centobuchi

63076 Monteprandone (AP) - Italy

0051-CPR-1876

EN 54-5:2000 + A1:2002

EN 54-7:2000 + A1:2002 + A2:2006

EN 54-17:2005

ED300

Intelligent analogue addressable multicriteria optical

smoke and class P heat detector with short cir

cuit iso-

lator for fire detection and fire alarm systems installed in

buildings

Essential characteristi

cs Performance

Nominal activation con-

dition/sensitivity, response delay

(response time) and performanc

under fire conditions

PASS

Operational reliability PASS

Tolerance to supply voltage PASS

Durability of

erational

reliability:

Temperature resi-

stance

PASS

Vibration resistance PASS

Humidity resistance PASS

Corro

sion resistance PASS

Electrical stability PASS

Detector class (EN54-5): A1R or B

Documents for the users

Declarations of Performance, Declarations of Conformity

and Certificates concerning to Inim Electronics S.r.l. pro-

ducts may be downloaded free of charge from the web

address www.inim.biz, getting access to Extended Access

and then selecting "Certifications" or requested to the e-

mail address info@inim.biz or requested by ordinary mail

to the address shown in this manual.

Manuals may be downloaded free of charge from the web

address www.inim.biz, getting access to Extended Access

and then selecting "Manuals".

Warnings and limitations

Enea series detectors must be used exclusively with

fully compliant, compatible control panels. Detectors

may not provide timely warning of fire if coverage is

limited by large obstructions (pillars, large machinery,

etc.). When installing or working on a fire detection

system, always refer to and comply with the esta-

blished standard regulations and codes. Appropriate

fire-risk assessment should be undertaken to deter-

mine the type of detectors required and their pla-

cements.

Manufacturer's details

Manufacturer: Inim Electronics S.r.l.

Production plant: Centobuchi, via Dei Lavoratori 10

63076 Monteprandone (AP), Italy

Tel: +39 0735 705007

Fax: +39 0735 734912

e-mail: info@inim.biz

Web: www.inim.biz

The persons authorized by the manufacturer to repair or

replace the parts of this system, hold authorization to

work on Inim Electronics brand devices only.

About this manual

Manual code: DCMIIN1PED

Revision: 260

the sole property of Inim Electronics S.r.l. No part may be

copied without written authorization from Inim Electronics
