Initiative Engineering F0525FF - Page 2

1.
2.
3.
4.
5.
6.
7.
8.
9.
10.
11.
12.
13
14.
15.
16.
17.
18.
19.
20.
21.
22.
23.
Handle
Upper Housing
Spring Washer
Disc Washer
Disc
Lower Housing
Inlet Union Assembly
Outlet Union Assembly
Drain Elbow Assembly
Top Distributor
Boom Distributor
Band
Handle Pin (6MM)
Spring
Bolt (M6X25)
Nut (M6)
Disc ‘O’ Ring (15.5X2.62)
Star Washer
Lower Housing Flange ‘O’ Ring (110X4.7)
Riser Pipe Adaptor ’O’ Ring (31.5X3.2)
Lower Housing ‘O’ Ring (65X4.5)
Union Assembly ‘O’ Ring (26.5X3)
Drain Elbow Assembly washer (24x31x2.6)
P1
P2
P3
P4
P5
P6
P7
P8
P9
P10
P11
P12
M1
M2
M3
M4
R1
R2
R3
R4
R5
R6
R7
PARTS LIST
EXPLODED VIEW
SR.NO. DESCRIPTION PART NO
