NIKE TL Cod. 0000136903 rev. 1.4 Page 2/4
3 PROGRAMMING
When the pump is powered, the switch is at the ON position (the display shows the message: on) and the signal is active
on the SIGNAL cable, the pump doses according to the cycle set with the keyboard. The dosing cycle consists of 4 phases:
1. Filter time (5 seconds) fixed.The display shows the message: a mobile “-“ 4 digits long
2. Programmable delay time (0-999 seconds) The display shows the message: del
3. Programmable dosing time (0-999 seconds) The display shows the message: run.
4. Programmable lock-out time (0-999 minutes) The display shows the countdown, which starts from the programmed
time and goes to zero. The pump does not dose during the lock-out time, even if it receives another signal on the
SIGNAL cable.
3.1 PASSWORD
The programming menu is accessed from Stand-by by pushing and holding the PROG key for at least 4 seconds; the first
item to appear is P (password) – by entering the correct password it is possible to enter and make changes in the menu.
To change the password scroll the menu up to item o and enter the desired password; this item may vary from 000 to 999
and save changes upon exiting the menu.
3.2 PROGRAMMING THE DELAY, DOSING AND LOCK-OUT TIMES
3.2.1 Programming the delay time
• Place the switch in the OFF position (standby). The display shows the message: Sby.
• Press the PROG key for more than 4 seconds until the display shows the message: 1-005.
• Press the PROG key. The red display’s first digit begins to blink.
• Press the UP key until the blinking digit displays the desired value.
• Press the PROG key. The next digit blinks.
• Press the UP key until the blinking digit displays the desired value.
• Press the PROG key. The next digit blinks.
• Press the UP key until the blinking digit displays the desired value.
• Press the PROG key. All of the display’s digits stop blinking.
3.2.2 Programming the dosing time
• Place the switch in the OFF position (standby). The display shows the message: Sby.
• Press the PROG key for more than 4 seconds until the green display shows the message: 1.
• Press the UP key until the green display shows the message: 2.
• Press the PROG key. The red display’s first digit begins to blink.
• Press the UP key until the blinking digit displays the desired value.
• Press the PROG key. The next digit blinks.
• Press the UP key until the blinking digit displays the desired value.
• Press the PROG key. The next digit blinks.
• Press the UP key until the blinking digit displays the desired value.
• Press the PROG key. All of the display’s digits stop blinking.
3.2.3 Programming the lock-out time
• Place the switch in the OFF position (standby). The display shows the message: Sby.
• Press the PROG key for more than 4 seconds until the green display shows the message: 1.
• Press the UP key until the green display shows the message: 3.
• Press the PROG key. The red display’s first digit begins to blink.
• Press the UP key until the blinking digit displays the desired value.
• Press the PROG key. The next digit blinks.
• Press the UP key until the blinking digit displays the desired value.
• Press the PROG key. The next digit blinks.
• Press the UP key until the blinking digit displays the desired value.
• Press the PROG key. All of the display’s digits stop blinking.
+
+
+
+
+
+
+
+
+
+
+
