OPERATIONS MANUAL
DOUBLE MITER SAW
IM-300 PL/ IM-300PL AL
05040235
SAP: 370/371
Http://www.inmes.com.br
!!! For your safety !!!
Read the manual instructions.

Table of Contents

Questions and Answers

  • J
    Jose KennedyAug 2, 2025
    What to do if my Inmes Saw motor does not work?
    • S
      santiagokatieAug 2, 2025
      If the motor of your Inmes Saw does not work, there are several potential causes: * The main feed cable may not be connected: ensure that the main feed cable is properly connected. * The circuit breaker might be off: turn the circuit breaker on. * The sawblade On/Off switch could be turned off: turn the switch on. * The handle for opening the hood may be open: turn the handle to ensure the hood is securely closed. If these steps do not resolve the issue, the main switch or On/Off switch button may be damaged, or the motor may be burned, requiring authorized service.
  • S
    Shannon StoutAug 7, 2025
    Why does my Inmes IM-300PL AL make rough cuts?
    • D
      Darrell DavisAug 7, 2025
      If your Inmes Saw is making rough cuts, several factors could be responsible: * The saw blade may not be sharp: have it sharpened. * The blade might be awkward or have missing teeth: replace the blade. * The saw blade could be incorrectly mounted: ensure the blade is mounted correctly. * The cutting speed may be too high: lower the cutting speed. If these steps don't help, the main shaft might be damaged, requiring authorized service.
  • P
    Paula RobertsAug 12, 2025
    What to do if my Inmes IM-300PL AL Saw circuit breaker trips frequently?
    • K
      Kelli WilliamsAug 12, 2025
      If your Inmes Saw frequently disconnects the circuit breaker, it could be due to: * Motor overload: feed work slower into the blade. * An undersized circuit breaker: install a right-sized circuit breaker. You may also need to check the motor bearings.
  • L
    Larry FowlerAug 16, 2025
    Why Inmes Saw has insufficient power when cutting?
    • A
      April ScottAug 16, 2025
      If your Inmes Saw is not providing sufficient power when cutting, consider the following: * The saw blade may not be sharp: have it sharpened. * The cutting speed might be too high: lower the cutting speed. * The saw blade may not be appropriate: use a saw blade with fewer teeth or an anti-kickback saw blade. Also, check if the saw belt is loose and adjust the belt tension.
  • S
    Sara KleinAug 21, 2025
    Why is my Inmes IM-300PL AL making excessive noise?
    • T
      Tracey LeAug 21, 2025
      If your Inmes Saw is producing excessive noise, it could be due to: * Damaged motor bearings. * A motor problem. * A dull saw blade. For motor bearing or motor issues, get authorized service. If the saw blade is not sharp, have it sharpened.
  • K
    kellymendozaAug 27, 2025
    How to fix inaccurate angle of cut on Inmes IM-300PL AL Saw?
    • M
      Michelle PrestonAug 27, 2025
      If the angle of cut on your Inmes Saw is not accurate, it could be due to: * A misaligned fence or saw blade: get authorized service. * An awkward profile: try another cut with a straight profile. * Movement during cutting: make sure the profile does not move during the cut. * A dull saw blade: have it sharpened. * Debris: clean up the machine to remove any debris between the profile and moulding fence.

Summary

Safety Instructions

Safety Signals

Explains DANGER, WARNING, and CAUTION safety signals used in the manual.

Before using the machine

Lists essential precautions and checks before operating the equipment.

Blade requirements

Details the specifications for saw blades, including diameter and thickness.

When installing the machine

Covers machine mounting, work area requirements, and circuit breaker installation.

Before each use

Outlines the necessary checks to perform before starting daily operation.

To reduce risk of injury

Provides crucial safety advice to prevent operator injury during use.

Protections

Advises on appropriate personal protective equipment (PPE) for safe operation.

Before leaving the machine

Specifies the steps to take before shutting down and leaving the machine.

Unpacking and Checking Contents

Unpacking the machine

Step-by-step instructions for unpacking the machine from its packaging.

Optional accessories

Lists available optional accessories that can enhance machine functionality.

Get to Know Your Double Miter Saw

Technical Specifications

Installation

Electric Installation

Details the requirements and procedures for electrical installation.

Correct rotation of electrical motors

Explains how to verify and correct motor rotation direction.

Lubricant oil level

Instructions for checking and filling the pneumatic lubricant oil level.

Air Supply

Specifies the requirements for the air supply and compressor.

Operation

Cutting adjustments

Covers adjustments related to cutting profiles and settings.

Minimum length of the profile to be cut

Instructions on setting the minimum length for profile cuts.

Safety Shields Adjustment

Guidance on properly adjusting the machine's safety shields.

Clamping System

Instructions for using and adjusting the workpiece clamping system.

Blades Descent Speed Adjustments

Procedure for adjusting the speed at which the saw blades descend.

Lubricant Spray (only for IM-300 PL AL)

How to fill and adjust the lubricant spray system for aluminum cutting.

Cutting the profile

Detailed steps for performing profile cuts accurately.

Recommendations

Advice on blade selection and dust collection system connection.

Maintenance

Changing the saw blade

Step-by-step guide for safely replacing the saw blade.

Adjustment of the saw belts

Instructions for checking and adjusting saw belt tension and wear.

Lubrification

Procedure for lubricating the machine's bearings and components.

Troubleshooting

Spare Parts of IM-300 PL;IM-300 PL AL

Optional Accessories

ARM EXTENSION

Visual representation of the arm extension accessory.

ROLLING ARM EXTENSION

Visual representation of the rolling arm extension accessory.

FLIP-FLOP MOLDING STOP

Visual representation of the flip-flop molding stop accessory.

DUST COLLECTOR

Visual representation of the dust collector accessory.

Assembling Extension Tables (Optional)

Aligning the Extension Table

Assembling the Additional Right Extension Table

Spare Parts List

Assembling the Right and Left Rolling Arm Extension IM-300 P; PL

Assembling the Right and Left Additional Rolling Arm Extension IM-300 P; PL

Left Rolling Arm Extension Spare Part List IM-300 P; PL

Right Rolling Arm Extension Spare Part List IM-300 P; PL

Left Additional Rolling Arm Extension Spare Part List IM-300 P; PL

Flip-Flop Molding Stop

Assembling the Flip-Flop Molding Stop

Instructions for assembling the flip-flop molding stop mechanism.

Installing the Flip-Flop Valve

Steps for correctly installing the flip-flop pneumatic valve.

Installing the Flip-Flop Switch

Procedure for installing and connecting the flip-flop switch.

Working with the Flip-Flop Molding Stop

Guide on how to use and adjust the flip-flop molding stop for cutting.

Spare Parts List

Assembling the Dust Collector

Spare Parts List
