Innotech SpitFIRE III - Page 27

Version 1.0 Preliminary 27
Smart Source and Punch through are ignored when programing and transmittong a macro
Program a macro
Learn flash2
Mac1-4 flash2
Smart (1SEC) flash1
Source flash1
IR tx button IR Xmit from XXX slot - IR Xmit complete
Learn (EOS) flash2
Program (EOM) flash3
other Macro (EOM) flash3
Search (EOM) flash3
Read Eeprom
Read EEPROM Send Start Address Hi
Start Hi Send Start Address Lo
Start Lo Send End Address Hi
End Hi Send End Address Lo
End Lo Data(n)
Echo Data(n+x) x++
Read Complete
Write Eeprom
Write EEPROM Send Start Address Hi
Start Hi Send Start Address Lo
Start Lo Send End Address Hi
End Hi Send End Address Lo
End Lo Start Write
Data(n) Echo
Data(n+x) x++ Echo
Write Complete
Size EEprom
Size EEPROM EEprom 128 or 64
