AC VOLTS
RESISTANCE (OHMS)
DC CURRENT (AMPS)
5
E
Range Resolution Accuracy Overload Protection
40mA 10µA
±(1.5% of 0.5A/250V fast fuse
reading (Input Voltage
400mA 100µA
+ 5 digits) Drop: <
0.2V.
±(2.5% of
Unfused; 15sec maximum
*15A 10mA reading
Input Voltage Drop: <
0.2V.
+ 5 digits)
*A waiting period of at least 15 minutes is necessary between
every 15 second testing period.
Range Resolution Accuracy Overload Protection
400Ω 0.1Ω
4kΩ 1Ω
±(1.0% of
40kΩ 10Ω
reading
400kΩ 100Ω
+ 5 digits)
250V DC/AC
4MΩ ±(2.0% of
40MΩ
10kΩ
reading
+ 5 digits)
Range Resolution Accuracy Overload Protection
400mV 100µV ±(1.2% of 250V DC RMS
reading
+8 digits)
4V 1mV
±(0.8% of
40V 10mV
reading
400V
+ 8 digits)
600V DC/AC RMS
600V
1V
±(1.2% of
reading
+ 8 digits)
Input impedance: 10MΩ for all ranges.
Frequency response: 50 - 400Hz
