AMTEK Version 7.4 2019-01 Page 14 ©Inomatic 2017-2019
2.5.1 Power supply cable/connector
V7.4 Processor board Power supply V6 (X1 or X2)
Please note that the power supply cable between the power supply and the
processor board should not exceed 15 meter.
The AMPSS 700V6 was designed to power our new AM antenna generation
whit AWG 20 antenna wires which require reduced loop voltage.
Operating the TX antenna with a higher voltage (> 50VDC) may result in higher
matching voltage which can damage the board.
