AMTEK Version 7.4 2019-01 Page 18 ©Inomatic 2017-2019
2.6.4 Single TX Antenna ((AMPRO 700V7.4 configured as “TX” Split system)
To reduce any noise influence, make sure:
1.) To place the power supply as close as possible to the TX antenna.
2.) To have the connection between the RX and the TX antenna (AMCTR 710
Connection Cable) as short as possible.
Hardware synchronization might only be necessary, if 2 or more TX antennas are used.
