AMTEK Version 7.4 2019-01 Page 6 ©Inomatic 2017-2019
2. AMTEK SYSTEM
2.1. Component Overview
The standard Mono system comprises the following components:
a.) Processor Board AMPRO 700V7.4
b.) Power Supply AMPSS 700V6 or higher
c.) Antenna AMTEK 150/250/350/450 or AMTEK 750
d.) Computer Cable LAN Cable AMCOM 710
e.) infoNet Software infoNet V5.0 or higher
2.1.1 Specifications:
Transmitter Operating Frequency 58 kHz (±200Hz)
Transmit Burst Duration 1.5ms or 1.6ms (can be set in InfoNet)
Max. Transmit Current 16A peak
Transmitter Coil Resistance 2 ohm (±5%)
Burst Repetition Rate 50Hz (60Hz)
Receiver Center Frequency 58 kHz
Alarm Audio level 97dBA
Environmental Ambient Temperature 0°C to 50°C
Relative Humidity 0 to 90% (Non-condensing)
Please note that the Version 7.4 processor board hardware can come with
different Firmware Versions. Please check the label on the processor if you are
not aware of your board’s firmware version.
