7
Pressing while in the Menu will move the menu back 1 step.
9. Menu and Up/Down arrows - These buttons along with the stop/back button allow for movement through
the menu.
During recording, the Up arrows turns ON the microphone & Down arrows turn OFF the microphone
Menu button is also the selector in the settings
10. Info Allows for quick access for serial number and software revision.
11. Aux and Text Writer buttons are not currently utilized.
12. Text-Writer Page Selector - 4 Pages A. Pg. 1 = No text. Distance counter only
B. Pg. 2 = Contractor Form Page
C. Pg. 3 = Client Form Page
D. Pg. 4 = Free Form Page
13. Main System Connection - Connection Port for the Video Interconnect Cable
This connection will power your Vutek Inspection Camera System
Make sure the two arrows are align, push to connect Twist and pull to disconnect
14. Main System Power Connection Connection for the external 12V DC Power Supply cord.
15. Video Out Jack - Used for external video display device.
16. Camera Test Port - Used for the camera head diagnostic and troubleshooting
17. Built-In Speaker - For audio playback
18. Built-In Microphone - For voice recordings Microphone is always activated.
To change microphone option, go into the menu setting, step 9.
19. USB Port Used to record video using a USB memory stick
