12
Insignia NS-HT51 5.1 Home Theater Speaker Package
www.insignia-products.com
Specifications
Satellite/center-channel speaker
Driver complement Midwoofer: 2.5-inch (64 mm) shielded with
paper cone, foam surround
Tweeters:
• 0.5-inch (13 mm) balanced dome
tweeter (satellite)
• 0.75-inch (19 mm) balanced dome
tweeter (center channel)
Frequency response 175 Hz~20 kHz
Impedance 8 ohms nominal
Power handling 50 W
Sensitivity 83dB@2.83V/1 m (3.28 feet)
Weight Satellite: 1.5 lbs. (0.68 kg)
Center channel: 2.0 lbs. (0.91 kg)
Dimensions Satellite: 6.31 × 4 × 3.75 inches
(160 × 102 × 95 mm)
Center channel: 4.13 × 9.13 × 3.75
(105 × 232 × 95 mm)
Subwoofer
Driver complement Woofer: 8-inch (203 mm) high-excursion
woofer
Amplifier power 50 W RMS
Crossover frequency Continuously variable 60 Hz~160 Hz
Frequency response 33 Hz~160 Hz
Enclosure Bass reflex design
Weight 17.5 lbs. (7.94 kg)
Dimensions 14.33 × 11.81 × 13.15 inches
(364 × 300 × 334 mm)
NS-HT51.fm Page 12 Thursday, March 6, 2008 6:46 AM
