Insinger 45SA5 - Scullery Machine Specifications; Capacity and Flow Rates; Weight and Electrical Requirements; 45 SA5-F1 Current Draw

UNDERCOUNTER SCULLERY MACHINE
Capacity per hour: 45 racks per hour
Wash tank capacity: 9.0 gallons
Wash pump: 1/2 hp 440/3/60 TEFC
Steam Consumption (tank and booster) at 16 psi min: 19 lb/hr average
94 lb/hr peak
Final rinse flow at 20 psig: 4.1 gal/min peak at 140° F min
36 gal/hr average flow
0.8 gal/rack
Exhaust requirements: Not required.
Peak drain flow: 9 gal/min
Weight:
Shipping: 381 lbs.
Operating: Dishwasher: 180
Electrical control panel: 30 lbs.
Current draw on 440/3/60:
45SA5-F1: 1.4 amps (dishwasher and booster)
45SA5-F2: 3.1 amps (dishwasher)
9.9 amps (9 KW booster)
45SA5-F2D: 3.1 amps (dishwasher)
19.8 amps (18 KW booster)
45SA5-F2NM: 3.1 amps (dishwasher)
12.6 amps (11.4 KW booster)
