28
®
PART 6 PARTS & ASSEMBLIES
CA-3 & DA-3 Technical Manual 2018 www.insingermachine.com 800-344-4802
1172-20 : Rinse Spray Nozzle Assembly
ITEM PART NO. DESCRIPTION QTY
1 1172-34 Spray Pipe 1
2 1172-35 Spray Pipe 1
3 D2-554-1 Plug 9/16-12 UNC-2A 2
4 D2828 Nozzle H1/8U-5015 6
REV C - 01/21/15
