29
®
PART 6 PARTS & ASSEMBLIES
CA-3 & DA-3 Technical Manual 2018 www.insingermachine.com 800-344-4802
1172-56 : Lower Spray Assembly
ITEM PART NO. DESCRIPTION QTY
1 1172-58 Lower Discharge Manifold 1
2 1172-70
1172-69
Wash Arm Hub with Bearing
Bearing (without Hub)
1
3 1172-73 Rinse Assembly 1
4 1172-62 Wash Arm Shaft 1
REV E - 06/05/98
