37
®
PART 6 PARTS & ASSEMBLIES
CA-3 & DA-3 Technical Manual 2018 www.insingermachine.com 800-344-4802
1172-84 : CA-3 Final Rinse Piping with I-3 Booster
ITEM PART NO. DESCRIPTION QTY
32 D2102A Steam Trap 1/2” IPS 1
33 D328F-A2A Pipe Plug 1/8” 2
34 D322F-E2-B1 Hex Reducer 3/4” MIPS x 1/4” FIPS 1
35 D320F-F1E1F1 Tee 1” FIPS x 3/4” FIPS 1” FIPS 1
36 D207A-B8-20 Copper Tubing 1” CTS x 5” Lg. 1
37 D207A-B8-18 Copper Tubing 1” CTS x 4 1/2” Lg. 1
38 925-48 Bracket 1
39 D207A-B8-103 Copper Tubing 1” CTS x 25 3/4” Lg. 1
40 D207A-B8-224 Copper Tubing 1” CTS x 56” Lg. 1
41 925-49 Bracket 1
42 D72A Pipe Clamp 1
43 979-42 S/S Upper Rinse Pipe (Consists of ** items) 1
44 D207C-L7-73 S/S Tubing 7/8” OD x 18 1/4” Lg. 1
45 D207A-B8-10 Copper Tubing 1” CTS x 4” Lg. 1
46 - - -
47 D2944 Solenoid Valve 1” IPS 1
48 D2249 Vacuum Breaker 1” IPS 1
49 - - -
50 - - -
51 D2390SP Split Jam Nut 1
52 D318E-E3-E2 Street Union 3/4” MIPS x 3/4” C 2
53 D207C-L7-168 S/S Tubing 7/8” OD x 42” Lg. 1
54 D316E-E3-E3 90
O
Elbow 3/4” C 1
55 D326F-F1 Lock Nut 1” IPS 1
56 D314C-ES-16 Nipple 3/4” IPS x 2” Lg. S/S 1
57 593-24 Cross 1” x 3/4” x 3/4” x 1/2” FIPS 1
58 D316E-E3-E1 90
O
Elbow 3/4” C x 3/4” FIPS 1
59 D316E-E3-E2 90
O
Elbow 3/4” C x 3/4” MIPS 1
60 D2390SP-1 Brass Union 1
** D315E-E3-E3 45
O
Elbow 3/4” C 1
** D315E-E3-E4 45
O
Street Elbow 3/4” C x 3/4” FTG 1
* Nickel Plated Copper or Brass
*
*
*
*
*
*
