PART 6 PARTS & ASSEMBLIES
CA-3 & DA-3 Technical Manual 2018 www.insingermachine.com 800-344-4802
1172-84 : CA-3 Final Rinse Piping with I-3 Booster
ITEM PART NO. DESCRIPTION QTY
1 D2379 Ball Valve 1” IPS 1
2 D2363 Ball Valve 1 1/4” IPS 1
3 D316F-F1-F2 90
O
Street Elbow 1” FIPS x 1” MIPS 1
4 D2447 “Y” Strainer 1 1/4” IPS 1
5 D2396 Steam Temperature Regulator 3/8” IPS 1
6 D316F-F3-F2 90
O
Elbow 1” C x 1” MIPS 3
7 D314F-GC-00 Close Nipple 1 1/4” IPS 1
8 D2947 Solenoid Valve 1” IPS 1
9 D316F-G1-G2 90
O
Street Elbow 1 1/4” FIPS x 1 1/4” MIPS 1
10 D322F-G2-F1 Hex Reducer 1 1/4” MIPS x 1” FIPS 1
11 D322F-H2-F1 Hex Reducer 1 1/2” MIPS x 1” FIPS 1
12 D207A-B8-10 Copper Tubing 1” CTS x 2 1/2” Lg. 1
13 D318A-F3-F2 Union 1” C x 1” MIPS 2
14 D314F-FC-00 Close Nipple 1” IPS 10
15 D2266 Pressure Regulator & Strainer 1” IPS 1
16 - - -
17 D2443 I-3 Booster (21”) 1
18 D320F-F1F1E1 Tee 1” FIPS x 1” FIPS x 3/4” FIPS 4
19 D2507 Pressure Relief Valve 3/4” IPS 1
20 D317A-F3-F2 Adapter 1” C x 1” MIPS 1
21 D322F-E2-A1 Hex Reducer 3/4” MIPS x 1/8 FIPS 2
22 D2497 Petcock 1/4” IPS 1
23 SK-1443 Pressure Gauge 1/4” IPS 1
24 D318F-F1-F1 Street Union 1” FIPS x 1” FIPS 1
25 D316A-F3-F3 90
O
Elbow 1” C 2
26 D322F-E2-D1 Hex Reducer 3/4” MIPS x 1/2” FIPS 1
27 D319A-F3-F2 90
O
Union Elbow 1” C x 1” MIPS 2
28 D322F-G2-F1 Hex Reducer 1 1/4” MIPS x 1” FIPS 2
29 D322F-E2-C1 Hex Reducer 3/4” MIPS x 3/8” FIPS 1
30 D314F-DS-24 Nipple 1/2” IPS x 3” Lg. 1
31 D316F-D1-D2 90
O
Street Elbow 1/2” FIPS x 1/2” MIPS 1
NOTE:
Pressure Regulator/Strainer (Item 15) to be furnished by others unless
specied on production card - use D-2448 “Y” Strainer as standard.
