CA-3
Pot and Pan Washer
SPECIFICATIONS
Capacity Per Hour 25 racks/150 sheet pans
Tank Capacity 31 gallons
Motor Size 5 hp
Electric Usage
(Electric booster must have 16
gallon holding tank)
5 kW wash tank
9 kW booster 40º rise
24 kW booster 70º rise
Steam Consumption
at 20 psi
40º rise
20 lbs./hr. tank
25 lbs./hr. booster average
238 lbs./hr. booster peak
70º rise
20 lbs./hr. tank
44 lbs./hr. booster average
417 lbs./hr. booster peak
Final Rinse Peak Flow
at 20 psi min.
11.2 gallons/minute
Final Rinse Consumption
at 20 psi min.
2.8 gallons/cycle
70 gallons/hour
Exhaust Requirements 300 CFM
Peak Rate Drain Flow 9 gallons/minute
Shipping Weight 800 lbs.
Note: Due to product improvement we reserve the right to change information
and specications without notice.
Current Draw Amps
230/1/60
208/3/60
240/3/60
480/3/60
380/3/50
Steam
N/A
17.4
15.9
7.9
9.6
Electric w/o booster
N/A
31.3
27.9
13.9
17.2
6245 State Road • Philadelphia, PA 19135 • PH: 800-344-4802 • FX: 215-624-6966 • www.insingermachine.com
3/2012
CONSTRUCTION- Hood and tank constructed of 14 gauge 18-8
type 304 S/S. Hood unit of all welded seamless construction. S/S
frame, legs and feet. All internal castings are non-corrosive lead
free nickel alloy or bronze.
DOORS- A front inspection/clean-out door and two
simultaneously opening operating doors. Operating doors
balanced by externally mounted springs. Extra large die formed
18-8 type 304 S/S doors ride in all S/S channels. A triple ply
leading edge on the door channels made of S/S.
PUMP- Centrifugal type “packless” pump with a brass petcock
drain. Construction includes ceramic seal and a balanced cast
impeller on a precision ground stainless steel shaft, extension or
sleeve. All working parts mounted as an assembly and removable
as a unit without disturbing pump housing. One 5 hp motor,
standard horizontal C-face frame, drip proof, internally cooled
with ball-bearing construction.
CONTROLS- Side-mounted control cabinet, NEMA 12 rated,
housing motor controls and overload protection, transformer,
contactors and all dishwasher integral controls. All controls safe
low voltage 24 VAC.
SPRAY SYSTEM- Wash and rinse spray systems made of 18-8
type 304 S/S pipe threaded into cast hub assemblies. Upper and
lower spray assemblies are interchangeable and are removable
without the use of tools.
WASH- 2 power spinning wash arms above and 2 power spinning
wash arms below, each designed with 8 high pressure action
cleansing holes.
FINAL RINSE- 2 power spinning wash arms above and 2 power
spinning rinse arms below, each designed with 3 nozzles.
DRAIN- Drain valve externally controlled. Overow assembly with
skimmer cap is removable with the use of simple tools for drain
line inspection. Heater is protected by low water level control.
*Note: Exhaust requirements are for duct connections only.
