PART 1 TECHNICAL INFORMATION
3
®
CA-3 & DA-3 Technical Manual 2018 www.insingermachine.com 800-344-4802
DA-3
Pot and Pan Washer
Automatic door type utensil washer with timed wash and rinse cycle
Capacity- 50 24” x 28” racks per hour or 276 bun/pans per hour or
184 steam table (2” thick) pans per hour
Fully automatic operation with power on/off button
Cycle starts when doors are closed
Rinse pressure regulator
Hold-Down Rack System for secure washing
Rollers make getting large racks in and out easier
STANDARD FEATURES
Wash tank heat: electric or steam injection
Pressure regulator
Single point electrical connection
Low water protection
Door safety switches
2 vent openings with adjustable damper
Inspection door
Vacuum breaker on all incoming water lines
Capillary thermometer for wash and final rinse
304 stainless steel construction
Stainless steel front panel
Automatic fill
Detergent connection provision
Hold-down rack system
Rollers for track
Manual bypass selector switch
Side-mounted control panel (NEMA 12)
Simplified scrap screen design
Interchangeable upper and lower spray arms
Standard frame drip proof motor
Rack assortment- 2 general utility, 2 bake sheets, 1 basket, 1 counter pan
Manifold clean-out brush
SureFire
®
Start-Up & Check-Out Service
OPTIONS
Stainless steel steam coil tank heat
Steam booster
Electric booster
Security package
Totally enclosed motor
Pressure reduction valve and line strainer
CSI - 11400 _____________
Approval _______________
Date ___________________
Project ________________
Item __________________
Quantity _______________
6245 State Road • Philadelphia, PA 19135 • PH: 800-344-4802 • FX: 215-624-6966 • www.insingermachine.com
The Hold-Down Rack System keeps pots and pans
secure during washing, eliminating damage to ware
and equipment.
Rollers make getting large racks in and out of the pot
washer easier.
DA-3
