PART 6 PARTS & ASSEMBLIES
CA-3 & DA-3 Technical Manual 2018 www.insingermachine.com 800-344-4802
1173-14 : DA-3 Final Rinse Piping with Electric Booster
ITEM PART NO. SIZE DESCRIPTION QTY
1 D207A-B8-80 - Copper Tubing 1” CTS x 20” Lg. 1
2 D2607 Solenoid 1” IPS 2
3 D314F-FC-00 - Nipple Close 1” IPS 5
4 D-2249 - Vacuum Breaker 1” IPS 2
5 D317A-F3-F2 - Adapter 1” C x 1” MIPS 7
6 D207A-B8-5 - Copper Tubing 1” CTS x 1 1/4” Lg. 1
7 D322F-E2-A1 - Hex. Reducer 3/4” MIPS x 1/8” FIPS 2
8 D207A-B8-12 - Copper Tubing 1” CTS x 3” Lg. 2
9 D316A-F3-F3 - 90
O
Elbow 1” C 7
10 D318F-F1-F1 - Street Union 1” FIPS x 1” FIPS 2
11 D326F-F1 - Locknut 1” IPS 2
12 D316E-E3-E1 - 90
O
Elbow 3/4” C x 3/4” FIPS 2
13 D314J-ES-16 - Nipple 3/4” IPS x 2” Lg. 2
14 593-24 A Cross 1” x 3/4” x 3/4” 1/2” IPS 2
15 D316E-E3-E2 - 90
O
Elbow 3/4” C x 3/4” MIPS 2
16 979-42 A S/S Upper Rinse Pipe 2
17 D318E-E3-E2 - Union 3/4” C x 3/4” MIPS 4
18 D2930SP-1 - Brass Union 2
19 D3-545 - O-Ring 2
20 979-41 A S/S Vertical Rinse Pipe Assembly 2
21 D207C-C7-73 - S/S Tubing 7/8” OD x 18 1/4” Lg. 2
22 D318A-F3-F3 - Union 1” C 2
23 D207A-B8-50 - Copper Tubing 1” CTS x 12 3/8” Lg. 2
24 D316A-F3-F1 - 90
O
Elbow 1” C x 1” FIPS 2
25 D207A-B8-51 - Copper Tubing 1” CTS x 12 3/4” Lg. 2
26 D207A-B10-48 - Copper Tubing 1 1/4” CTS x 12” Lg. 1
27 D329-5 - Drain Cock 1/4” IPS 2
* Chrome Plated Brass or Bronze
** 24V (unless otherwise noted)
**
*
*
*
*
*
