40
®
PART 6 PARTS & ASSEMBLIES
CA-3 & DA-3 Technical Manual 2018 www.insingermachine.com 800-344-4802
1173-14 : DA-3 Final Rinse Piping with Electric Booster
ITEM PART NO. SIZE DESCRIPTION QTY
28 D322F-F2-B1 - Reducer 1” MIPS x 1/4” FIPS 2
29 D320F-F1F1F1 - Tee 1” IPS 2
30 D2390SP - Split Jam Nut 2
31 D207A-B8-38 - Copper Tubing 1” CTS x 9 1/2” Lg. 2
32 D207A-B8-64 - Copper Tubing 1” CTS x 16” Lg. 2
33 D207A-B10-18 - Copper Tubing 1 1/4” CTS x 4 1/2” Lg. 1
34 D323F-F2-E1 - Reducer 1 1/4” MIPS x 3/4” FIPS 1
35 D323F-E2-D1 - Reducer 3/4” MIPS x 1/2” FIPS 1
36 D320F-F1F1E1 - Tee 1 1/4” IPS 2
37 D328F-E2A - Pipe Plug 3/4” IPS 1
38 925-48 A Support Bracket 1
39 D-2266A - Pressure Regulator & Strainer 1 1/4” IPS 1
40 D316F-F1-F2 - 90
O
Street Elbow 1” IPS 2
41 D2363 - Ball Valve 1 1/4” IPS 1
42 D207A-B8-152 - Copper Tubing 1” CTS x 38” Lg. 1
43 925-49 A Support Bracket 2
44 D72-A A Pipe Clamp 2
45 D316A-F3-F4 - 90
O
Elbow 1” C x 1” FTG 2
46 D328F-A2A - Pipe Plug 1/8” IPS 2
47 D207A-B8-80 - Copper Tubing 1” CTS x 20” Lg. 1
48 D207A-B8-168 - Copper Tubing 1” CTS x 42” Lg. 2
49 D320A-G3-F3-F3 - Tee 1 1/4” C x 1” C x 1” C 1
50 D320F-G1-G1-G1 - Tee 1 1/4” IPS 2
51 D316F-G1-G2 - 90
O
Street Elbow 1 1/4” IPS 1
52 D314F-GC-00 - Nipple Close 1 1/4” IPS 3
53 D317A-F3-F2 - Adapter 1 1/4” C x 1 1/4” MIPS 1
54 D316A-G3-G3 - 90
O
Elbow 1 1/4” C 1
NOTE:
Pressure Regulator/Strainer (Item 39) to be furnished by others unless specied on
production card - use D-2448 “Y” Strainer as standard.
*
