PART 6 PARTS & ASSEMBLIES
CA-3 & DA-3 Technical Manual 2018 www.insingermachine.com 800-344-4802
1173-31 : DA-3 Final Rinse Piping with Two I-3 Boosters
ITEM PART NO. DESCRIPTION QTY
1 D2363 Ball Valve 1 1 /4” IPS 2
2 D314F-GC-00 Close Nipple 1 1/4” IPS 5
3 D316F-G1-G2 90
O
Street Elbow 1 1/4” IPS 2
4 D2447 “Y” Strainer 1 1/4” IPS 2
5 D2267 Steam Temperature Regulator 1 1/4” IPS 2
6 D319A-G3-G2 90
O
Union Elbow 1 1/4” C x 1 1/4” MIPS 2
7 D320F-G1G1G1 Tee 1 1/4” IPS 2
8 D328F-G2A Square Plug 1 1/4” IPS 2
9 D317A-G3-G2 Adapter 1 1/4” MIPS x 1 1/4” C 2
10 D207A-B10-33 Copper Tubing 1 1/4” CTS x 8 1/4” Lg. 1
11 D322F-H2-G1 Hex Reducer 1 1/2” MIPS x 1 1/4” FIPS 2
12 D2379 Ball Valve 1” IPS 2
13 D316F-F1-F2 90
O
Street Elbow 1” IPS 4
14 D314F-FC-00 Close Nipple 1” IPS 15
15 D2266 Pressure Regulator & Strainer 1” IPS 2
16 979-24 Bracket 1
17 D2243 I-3 Booster (21”) 2
18 D320F-F1F1E1 Tee 1” FIPS x 1” FIPS x 3/4” FIPS 7
19 D2507 Pressure Relief Valve 3/4” IPS 2
20 - - -
21 D322F-E2-A1 Hex Reducer 3/4” MIPS x 1/8” FIPS 4
22 D2497 Petcock 1/4” IPS 2
23 SK-1433 Pressure Gauge 1/4” IPS 2
24 D207A-B10-22 Copper Tubing 1 1/4” CTS x 5 1/2” Lg. 2
25 D316A-F3-F3 90
O
Elbow 1” C 6
26 D207A-B8-20 Copper Tubing 1” CTS x 5” Lg. 3
27 D316A-F3-F2 90
O
Elbow 1” C x 1” MIPS 2
28 D322F-G2-F1 Hex Reducer 1 1/4” MIPS x 1” FIPS 4
29 D332F-E2-D1 Hex Reducer 3/4” MIPS x 1/2” FIPS 2
30 D314F-DS-24 Nipple 1/2” IPS x 3” Lg. 2
31 D316F-D1-D2 90
O
Street Elbow 1/2” IPS x 1/2” MIPS 2
32 D2102A Steam Trap 1/2” IPS 2
33 D318F-F1-F1 Street Union 1” FIPS x 1” FIPS 2
34 D328F-A2A Square Plug 1/8” IPS 4
35 D320F-F1E1F1 Tee 1” FIPS x 3/4” FIPS x 1” FIPS 2
36 D207A-B8-18 Copper Tubing 1” CTS x 4 1/2” Lg. 2
NOTE:
Pressure Regulator/Strainer (Item 15) to be furnished by others unless
specied on production card - use D-2447 “Y” Strainer as standard.
