44
®
PART 6 PARTS & ASSEMBLIES
CA-3 & DA-3 Technical Manual 2018 www.insingermachine.com 800-344-4802
1173-31 : DA-3 Final Rinse Piping with Two I-3 Boosters
ITEM PART NO. DESCRIPTION QTY
37 D207A-B8- Copper Tubing 1” CTS x 10 5/8” Lg. 2
38 925-48 Bracket 1
39 D207A-B8-108 Copper Tubing 1” CTS x 27” Lg. 1
40 D207A-B8-44 Copper Tubing 1” CTS x 11” Lg. 1
41 D207A-B8-222 Copper Tubing 1” CTS x 55 1/2” Lg. 1
42 D207A-B8-218 Copper Tubing 1” CTS x 54 1/2” Lg. 1
43 D207A-B10-52 Copper Tubing 1 1/4” CTS x 13” Lg. 1
44 D319A-F3-F2 Union Elbow 1” C x 1” MIPS 2
45 D316A-G3-G3 90
O
Elbow 1 1/4” C 2
46 925-49 Bracket 2
47 D72A Pipe Clamp 2
48 979-42 S/S Upper Rinse Pipe 2
49 D207C-L7-73 S/S Tubing 7/8” OD x 18 1/4” Lg. 2
50 D314F-GS-48 Nipple 1 1/4” x 6” Lg. 1
51 D207A-B8-12 Copper Tubing 1” CTS x 3” Lg. 2
52 D2944 Solenoid Valve 1” IPS 2
53 D2249 Vacuum Breaker 1” IPS 2
54 D317A-F3-F2 Adapter 1” C x 1” MIPS 8
55 D314F-GA-20 Nipple 1 1/4” IPS x 2 1/2” Lg. 1
56 D207A-B8-16 Copper Tubing 1” CTS x 4” Lg. 2
57 D318E-E3-E2 Street Union 3/4” C x 3/4” MIPS 4
58 D207C-L7-168 S/S Tubing 7/8” OD x 42” Lg. 2
59 D316E-E3-E3 90
O
Elbow 3/4” C 2
60 D326F-F1 Lock Nut 1” IPS 2
61 D314C-ES-14 Nipple 3/4” IPS x 1 3/4” Lg. S/S 2
62 593-24 Cross 1” x 3/4” x 3/4” x 1/2” FIPS 2
63 D316E-E3-E1 90
O
Elbow 3/4” C x 3/4” FIPS 2
64 D316E-E3-E2 90
O
Elbow 3/4” C x 3/4” MIPS 2
65 D2390SP-1 Brass Union 2
66 D322F-E2-B1 Hex Reducer 3/4” MIPS x 1/4” FIPS 2
67 D2390SP Split Jam Nut 2
68 D319A-F3-F3 Union Elbow 1” C x 1” C 2
69 D315E-E3-E3 45
O
Elbow 3/4” C x 3/4” C 2
70 D315E-E3-E4 45
O
Elbow 3/4” C x 3/4” CFTG 2
71 D319A-G3-G2 Union Elbow 1 1/4” C x 1 1/4” MIPS 1
* Nickel Plated Copper or Brass
*
*
*
*
*
*
*
*
