PART 7 ELECTRICAL SCHEMATICS AND PARTS
CA-3 & DA-3 Technical Manual 2018 www.insingermachine.com 800-344-4802
SK-3241 : Control Panel Layout
ITEM PART NO. DESCRIPTION QTY
12 DE3-43 Relay Hold Down Spring AR
13 DE9-84 DIN Rail (35mm) 1
14 DE3-42 DIN Rail (15mm) 1
15 DE3-39 Terminal Section 16
16 DE3-40 Terminal End Cover Plate 1
17 DE3-41 Terminal End Clamp 2
18 DE9-251 Temperature Control Board AR
19 DE7-35 Timer (Liquid Level) 1
20 DE3-9 Terminal Block Assembly 1
21 DE3-152 Distribution Block 1
22 D309C-GC-4G Grounding Stud, 1/4-20 1
23 D313C-G5 Lockwasher 1/4” 1
24 D312C-GC-2 Hex Nut, 1/4-20 1
25 SK-2622 Legend Decal 1
26 DE5-11 Selector Switch 1
27 DE5-16 Cycle Switch 1
28 DE5-11 Switch, DPDT (Power On) 1
29 DE9-13 Boot 3
30 DE9-107 Pilot Light (Heat & Power On) 1
31 DE9-108 Pilot Light (Wash) 1
32 DE9-109 Pilot Light (Rinse) 1
33 DE9-43 Circuit Breaker (5A) 1
34 979-23 Control Box 1
35 DE2-12 Relay 1
36 DE3-25 Relay Base 1
37 DE9-185 Fuse Block (100 VA Fan XFMR) 1
38
Fuse 100 VA Transformer
2
DE9-166 460V, FNQ-R-.75
DE9-168 220 - 230V, FNQ-R-1.4
DE9-200 208V, FNQ-R-1.5
39 DE2-60 Overload Base AR
PARTS NOT SHOWN
- Electric Immersion Heater (5 kW)
1
DE13-SD73 440 - 480V, 3 PH
DE13-SD53 380V, 3 PH
DE13-SD43 220 - 240V, 3 PH
DE13-SD23 208V, 3PH
- DE6-34 Dry XFMR (100 VA For Fan) 1
- DE9-252 Temperature Sensor AR
