FUSE SIZING CHART
MODEL TYPE 208VAC / 3PH 230VAC / 3PH 380VAC / 3PH 460VAC / 3PH
CA-3(C)
Steam Heat 25A 20A 15A 10A
Electric Heat 35A 35A 20A 20A
Gas Heat 25A 20A 15A 10A
DA-3
Steam Heat 40A 35A 25A 20A
Electric Heat 60A 50A 30A 25A
PART 2 INSTALLATION INSTRUCTIONS
CA-3 & DA-3 POT AND PAN WASHERS
INSTALLATION INSTRUCTIONS
These installation instructions are intended for qualied
equipment installers.
PLACEMENT
Carefully uncrate the machine. Take caution not to
damage components which may be mounted on the
top or sides of the machine.
Set unit in place and adjust the feet to level the
machine.
TABLING
Load and unload tables should be pitched towards the
machine to return excess water into the machine.
Fasten the tables to the load and unload side of the
machine. Most installations require fastening the turn-
down lip of the dish tables to the side of the machine
with athead counter-sunk screws.
The table design should provide horizontal clearance
of 30” for servicing.
ELECTRICAL CONNECTIONS
Connect electrical lines sized for the correct voltage,
current and phase of the machine. These should
agree with the machine requirements indicated on
the nameplate and labels on the control panel. The
below Fuse Sizing Chart should be used as a guide for
proper line protection.
CAUTION:
Connections must be made to a circuit breaker or
fused disconnect as provided by the end-user and
required by local codes. A laminated wiring diagram
is inside the control panel.
7
®
CA-3 & DA-3 Technical Manual 2018 www.insingermachine.com 800-344-4802
Machines not provided with a single-point connection
require two separate electrical connections for:
1. pumps and control circuit
2. wash tank heater(s)
If an electrical booster is provided connect the power
directly to the booster.
CAUTION:
As with any 3 phase system, an electrician must
check all motors for proper phasing, i.e., Pump
motors must be running in direction indicated by
arrow on housing.
