5
❷ Expand the frame out by pulling on the side rails unl the
locking spring pins insert into the holes on both ends. Check
to ensure the frame is securely locked together. Figure 3.2
❸ Li the right side wall up into a vercal posion. Figure 3.3
2
Right wall
Figure 3.2 Figure 3.3
3
Side rail
Side rail
Locking spring
pin in hole
