Instruction Manual InstruTech CVM-211 "Stinger" Convection Vacuum Gauge Module
InstruTech, Inc page 14
Table 1 - Non-Linear Analog Output Voltage vs Pressure, for Selected Gases
The following Stinger part numbers ending with the letter “A” provide a Non-Linear Analog output:
CVM211GAA, CVM211GBA to…CVM211GHA . Refer to next page if you have ordered a Stinger with a Log-Linear Analog
output.
N2 Ar He O2 CO2 Kr Freon12 Freon22 D2 Ne CH4
0 mTorr 0.3751 0.3750 0.3750 0.3750 0.3750 0.3750 0.3750 0.3750 0.3750 0.3750 0.3750
0.1 mTorr 0.3759 0.3757 0.3755 0.3760 0.3760 0.3755 0.3760 0.3760 0.3760 0.3757 0.3766
0.2 mTorr 0.3768 0.3760 0.3765 0.3770 0.3770 0.3768 0.3780 0.3780 0.3770 0.3763 0.3780
0.5 mTorr 0.3795 0.3780 0.3790 0.3800 0.3810 0.3772 0.3820 0.3810 0.3810 0.3782 0.3825
1 mTorr 0.3840 0.3810 0.3820 0.3840 0.3850 0.3790 0.3880 0.3880 0.3860 0.3810 0.3896
2 mTorr 0.3927 0.3870 0.3890 0.3920 0.3950 0.3840 0.4010 0.4000 0.3960 0.3880 0.4030
5 mTorr 0.4174 0.4030 0.4090 0.4170 0.4120 0.3950 0.4370 0.4320 0.4250 0.4050 0.4380
10 mTorr 0.4555 0.4290 0.4410 0.4530 0.4620 0.4150 0.4880 0.4800 0.4700 0.4330 0.4920
20 mTorr 0.5226 0.4770 0.4970 0.5210 0.5360 0.4510 0.5810 0.5660 0.5490 0.4840 0.5840
50 mTorr 0.6819 0.5950 0.6370 0.6790 0.7050 0.5440 0.7780 0.7640 0.7270 0.6080 0.7960
100 mTorr 0.8780 0.7450 0.8140 0.8680 0.9000 0.6680 1.0090 0.9900 0.9440 0.7680 1.0530
200 mTorr 1.1552 0.9620 1.0680 1.1410 1.1790 0.8470 1.3150 1.2910 1.2650 1.0020 1.3920
500 mTorr 1.6833 1.3860 1.5890 1.6640 1.6680 1.1940 1.8260 1.8050 1.9140 1.4690 2.0140
1 Torr 2.2168 1.8180 2.1640 2.1950 2.1720 1.5360 2.2570 2.2470 2.6030 1.9760 2.6320
2 Torr 2.8418 2.3330 2.9390 2.8140 2.6950 1.9210 2.6470 2.6660 3.5080 2.6310 3.3130
5 Torr 3.6753 3.0280 4.3870 3.6720 3.3160 2.4290 3.0290 3.0900 5.0590 3.7150
10 Torr 4.2056 3.4800 5.7740 4.2250 3.6700 2.7340 3.2040 3.3300 6.3610 4.6050 4.6990
20 Torr 4.5766 3.8010 7.3140 4.6200 3.9030 2.9660 3.3080 3.4140 5.4060 5.1720
50 Torr 4.8464 4.0370 4.9160 4.0710 3.0750 3.4300 3.5090 6.1590 5.5830
100 Torr 4.9449 4.1220 5.0260 4.1540 3.1340 3.6180 3.6600 6.4830 5.7200
200 Torr 5.0190 4.1920 5.1060 4.3360 3.2690 3.8270 3.8830 6.6610 5.8600
300 Torr 5.1111 4.2830 5.2000 4.5020 3.3840 3.9380 4.0050 6.7260
400 Torr 5.2236 4.3860 5.3150 4.6210 3.4660 4.0160 4.0880 6.7670 6.1030
500 Torr 5.3294 4.4770 5.4220 4.7080 3.5260 4.0760 4.1510 6.8030
600 Torr 5.4194 4.5500 5.5150 4.7750 3.5730 4.1240 4.2030 6.8430 6.3420
700 Torr 5.4949 4.6110 5.5920 4.8300 3.6130 4.1660 4.2470 6.8900
760 Torr 5.5340 4.6430 5.6330 4.8600 3.6320 4.1900 4.2710 6.9200
800 Torr 5.5581 4.6630 5.6580 4.8770 3.6450 4.2030 4.2860 6.9420 6.5190
900 Torr 5.6141 4.7060 5.7130 4.9190 3.6740 4.2370 4.3210 7.0000
1000 Torr 5.6593 4.7450 5.7620 4.9550 3.6900 4.2700 4.3540 7.0560 6.6420
True Total
Pressure
Note: By design, these values are identical to the outputs from Helix/Granville-Phillips Convectron
®
gauges, Mini-
Convectron
®
modules, and Controllers, so that equivalent units can be interchanged without affecting your
process system or software.
