Instruction Manual InstruTech CVM-211 "Stinger" Convection Vacuum Gauge Module
InstruTech, Inc page 2
Table of Contents
page
Introduction / General Information
Description 3
Specifications 3
Options & Accessories 3
Safety
General 4
Service & Operation 4
Electrical 4
Grounding 4
Overpressure 4
Gases other than N
2
5
Flammable/Explosive Gases 5
Installation
Mechanical 5
Position 5
Vibrations 5
Fittings 5
Electrical 6
Connector & Pinouts 6
Setup & Operation
User Interface Basics 7
Setting up the Module 7
Service
Calibration 8
Maintenance 8
Cleaning 8
Troubleshooting 8
Module & Gauge Replacement 9
Factory Service and Support 9
Trademarks & Acknowledgements
Warranty
9
20
Appendices
A. User Interface Map
B. Using thermal vacuum gauges with different gases
C. Contamination & Cleaning
