Installation Instructions No. 9999-067-0
_________________________________________________________________________________________________
_____________________________________________________________________________________________
E7250E_01.doc Rel. 1 vom 11.07.2005 4
Installation options: The electronic lock must always be located at right angles to the keypad
(four installation positions, each offset 90° from the other).
Sample installation
CombiControl 7238CombiLock 7251
The bolt may not be subjected to tension or pressure after installation. Do not use lubricants
or any other substances on or in the electronic lock.
It is recommended that a security and functional test be made by personnel trained by cawi
after about 10,000 closing cycles.
