- GB.8-V1 -
SET CAPACITY ◄►
↵
×××× SAE
GOOD & PASS
××.××V ×××× SAE
GOOD & RECHARGE
××.××V ×××× SAE
RECHARGE & RETEST
××.××V ×××× SAE
TESTING
IS BATTERY ◄►
↵
CHARGED? YES
8.
Press the ◄ ► key to input
the battery capacity of CCA：
• SAE：40~2000
• EN：40~2100
• IEC：30~1500
• DIN：25~1300
• JIS：By Battery Type No.
Press «ENTER» to begin the test.
9.
Test the battery for few
seconds.
10.
Press the ◄ ► key to select
battery fully charged or not if
tester asks. Press «ENTER»
to confirm choice.
11.
When the test is completed, the display shows the
actual volts and the actual CCA or %. {Press the◄ ►
key to select: SOH (STATE OF HEALTH) or SOC
(STATE OF CHARGE)}.
One of six results will be displayed:
GOOD & PASS :
The battery is good & capable
of holding a charge.
GOOD & RECHARGE :
The battery is good but needs
to be recharged.
RECHARGE & RETEST :
Battery is discharged, the
battery condition cannot be
determined until it is fully charged. Recharge & retest
the battery.
